Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
Specifications
Brand Name :
Ulinkcon
Model Number :
M19
Certification :
CE/Rohs/TUV/UL
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability :
100000 pairs Montly
Delivery Time :
3~6working days
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
Connector type :
Quick connector
Pin :
10Pin
Material :
Nylon
Current rating :
5A
Rated voltage :
300V
Application Scenarios :
Outdoor LED Displays/Smart Building Control Systems
Description

M19 10 Pin Waterproof Quick Disconnect Wire Connectors ODM IP67 Circular Connectors


Quick Description


  • Core Specification: Standard M19 circular structure, 10-pin configuration, designed for plug-and-socket mating. Supports multi-channel signal and power synchronous transmission, compatible with 18-24AWG wires, suitable for medium and low voltage working scenarios.
  • Quick Lock Advantage: Adopts one-click quick locking mechanism, enabling fast and precise mating of plug and socket without auxiliary tools. The locking is firm and anti-loosening, effectively preventing accidental disconnection caused by vibration or external pulling, greatly improving installation and maintenance efficiency.
  • Waterproof & Durable Performance: Equipped with integrated sealing structure and high-quality silicone sealing ring, achieving IP67 waterproof and dustproof rating. It can resist rain, dust, oil stains and other harsh environmental erosion; the shell is made of high-strength engineering plastic, with anti-aging, corrosion-resistant and temperature-resistant (-40℃ to 105℃) properties, ensuring long-term stable use.
  • Application Scenarios: Widely used in industrial control systems, outdoor electronic equipment, automotive accessories, security monitoring devices, smart home systems and other fields that require reliable and efficient connection of multi-channel signals .


Electrical Parameters
Number of Poles 10Pin
Current Rating 5A max.
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s.


Application industries


  • Growth Lights
  • Communications Application
  • product coding machines
  • inventory product coding
  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery


Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min) when mated
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone


Main Features


  • Push lock quick release system
  • Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
  • 3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
  • 6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
  • Field assembly version:both wire to wire and wire to board options
  • Current rated 5A for long time working
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome


Operation Parameters
Voltage Rating 300VAC max
Current Rating 5A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 8.0mm ~ 10.0mm
Max.Cable Cross Section Area 0.5mm2 ~ 2.5mm2


Design Sketch


Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors


Quick Lock 10 Pin Waterproof Connector M19 Plug And Socket Connectors
