Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Online Food Processing Industry Needle Metal Detector Equipment JZD-366
Specifications
waterproof :
IP66
Certification :
ISO,HACCP
customized support :
OEM, ODM, OBM
Raw material :
SUS304
type :
New
Place of Origin :
Guangdong, China
warranty :
1year
alarm :
audible and visual alarm ,automatic stop
belt color :
customized
certification approval :
ISO,HACCP
Brand Name :
JUZHUO
conveyor loading capacity :
25kg(customized)
MOQ :
5
conveyor speed :
22m/minutes(adjustable)
belt material :
PU
Model Number :
JZD-366
Price :
$4,680
Description
Online Metal Detectors for Food Processing Industry, Needle Metal Detector for Food JZD-366
Product Overview

The JZD-366 is an advanced LCD display intelligent digital metal detector featuring two-way signal detection circuit technology. It employs sophisticated electromagnetic detection and digital signal processing technology, utilizing the latest DDS (Direct Digital Synthesizer) and DSP (Digital Signal Processor) hardware combined with advanced detecting algorithms, self-study capabilities, and full digital regulating functions to ensure stable and dependable metal detection performance.

Applications

The JZD-366 digital metal detector is primarily used for detecting metal impurities in various food products including bakery items, pizza, hamburgers, puree, sauce, vegetable tobaccos, and other applications requiring metal detection. It is designed to operate effectively in challenging work environments including high temperature, low temperature, damp, dry, dusty, and dewy conditions.

Main Features
  • LCD display screen control panel with English and Chinese language options
  • Capable of detecting impurities in products packaged with evaporating aluminum
  • Can store up to 100 different product detection parameters for easy switching between product applications
  • Automatic identification learning functions that efficiently overcome product material effects
  • Detection head utilizes dual channel detecting circle technology from Germany with rectangular aperture (indivisible)
  • ADLINE microprocessor controller system
  • Compliance with IFS standards and certifications including HACCP, CE & ISO 9001
  • Strong suppression for product effects in aquatic foods, frozen foods, and pickled foods
  • Excellent anti-interference and shock proof capabilities
  • Easy disassembly and convenient cleaning design
Technical Parameters
Parameter Specifications
Model JZD-366
Inspection Window Width (mm) 400 (customization available)
Inspection Height (mm) 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400
Detection Sensitivity - Fe (Φmm) ≥0.6 | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0
Detection Sensitivity - Non-Fe (Φmm) ≥1.0 | ≥1.2 | ≥1.5 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5
Detection Sensitivity - 304SUS (Φmm) ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5
Alarm System Audible and visual alarm with automatic stop
Raw Material SUS304
Machine Dimensions (mm) 160(L) × 90(W) × 100(H) cm (standard size)
Net Weight 330kg (standard size)
Power Supply 110V/220V/380V 50Hz/60Hz, 90W
Conveyor Speed 25-30m/min (customizable to customer requirements)
Conveyor Height 650mm±50mm (standard, customizable to customer needs)
Note: The above sensitivity specifications are measured without bearing any parts. Actual sensitivity may vary depending on product nature and temperature. Automatic rejection equipment can be installed according to customer requirements.
