Online Industrial Needle Metal Detector Inspection Equipment System JZD-366

Specifications

Model Number :

JZD-366

customized support :

OEM, ODM, OBM

conveyor load :

25kg(customized)

waterproof :

IP66

Brand Name :

JUZHUO

alarm :

audible and visual alarm ,automatic stop

Raw material :

SUS304(stainless steel)

MOQ :

control panel :

LCD display screen

conveyor speed :

22m/minutes(Variable speed,adjustable)

products name :

Industrial metal detector,Needle Metal Detector JZD-366

Place of Origin :

Guangdong, China

certification aprpoval :

CE,ISO9001,HACCP

warranty :

1year

type :

New

Description

Online Industrial Metal Detector, Needle Metal Detector JZD-366

Product Overview

Model JZD-366 is an LCD display intelligent/digital metal detector featuring two-way signal detection circuit technology. It adopts advanced electromagnetic detection and digital signal processing technology, utilizing the latest DDS (Direct Digital Synthesizer) and DSP (Digital Signal Processor) in hardware, combined with advanced detecting algorithms, self-study, and full digital regulating functions. This makes the metal detector's detecting capacity more stable and dependable, significantly improving detection effectiveness.

Applications

Model JZD-366 digital metal detector is primarily used for checking metal impurities that mix or drop in bakery products, pizza, hamburger, puree, sauce, vegetables, tobaccos, and other occasions requiring metal detection. It can be applied in high temperature, low temperature, damp, dry, dusty, dewy, and other poor work environments.

Main Features

LCD display screen control panel with English and Chinese language options
Can detect impurities in products packaging with evaporating aluminum
Can record up to 100 different product parameters for detection with simple operation for frequent product changes
Automatic identification learning functions that efficiently overcome product material effects
Detection head adopts dual channel detecting circle from German detection technology with rectangular aperture (indivisible)
Control system - ADLINE microprocessor controller
Conforms to IFS standard with HACCP, CE & ISO 9001 certifications
Strong suppression for product effect of aquatic food products, frozen foods & pickled foods
Strong anti-interference and shock proof capabilities
Easily disassembled and conveniently cleaned

Technical Parameters

Parameter	Specifications
Model	JZD-366
Width of inspection window (mm)	400 (customization available)
Height of inspection (mm)	100 \| 120 \| 150 \| 200 \| 250 \| 300 \| 350 \| 400
Detection Sensitivity - Fe (Φmm)	≥0.6 \| ≥0.8 \| ≥1.0 \| ≥1.2 \| ≥1.5 \| ≥2.0 \| ≥2.5 \| ≥3.0
Detection Sensitivity - Non-Fe (Φmm)	≥1.0 \| ≥1.2 \| ≥1.5 \| ≥2.5 \| ≥3.0 \| ≥3.5 \| ≥4.0 \| ≥4.5
Detection Sensitivity - 304SUS (Φmm)	≥1.2 \| ≥1.5 \| ≥2.0 \| ≥2.5 \| ≥3.0 \| ≥3.5 \| ≥4.0 \| ≥4.5
Alarm System	Audible and visual alarm, automatic stop
Raw Material	SUS304
Normal Machine Size (mm)	160(L)cm × 90(W)cm × 100(H)cm (Based on normal size)
Net Gross	330kg (based on normal size)
Electrical Source (Power)	110V/220V/380V 50Hz/60Hz (Power) 90W
Conveyor Speed	25-30m/min (can be designed according to customer requirements)
Conveyor Height	650mm±50mm (normal) - can be manufactured to customer needs

Note: The above sensitivity is judged by the machine without bearing any parts. Actual sensitivity has relation with the nature and temperature of the products, etc. Auto-rejection equipment can be installed according to customer requirements.
