Multi Scene Stable Vertical CNC Lathes Turning Center EET 200/200M Series
Multi Scene Stable Vertical CNC Lathes Turning Center EET 200/200M Series
Multi Scene Stable Vertical CNC Lathes Turning Center EET 200/200M Series
Multi Scene Stable Vertical CNC Lathes Turning Center EET 200/200M Series
Specifications
Brand Name :
Li Zhun
Model Number :
EET 200/200M
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10000 per year
Delivery Time :
15-30 work days
Packaging Details :
Wooden Box
Certification :
SGS
Product Name :
CNC Turning Center
Condition :
New
Warranty :
1 Year
Spindle Speed :
4500
Weight :
4600
Description

High Rigidity High Precision CNC Turning Center EET 200/200M Series

This series adopts motorized spindle, which can save space more effectively and is easy to install, and the motorized spindle is more superior in rigidity, output and other characteristics. The highest speed on X-axis is 30m/min, on Z-axis is 36m/min. The fast moving speed can greatly improve the auxiliary time and work efficiency. This series is also equipped with an upgraded Siemens 828D numerical control system to provide optimal performance for the operator.

Main Technical Parameters

ITEM MODELS EET200/600U EET200M/500U
X AXIS TRAVEL mm 210 210
Z AXIS TRAVEL mm 600 520
X RAPID FEED SPEED m/min 30 30
Z RAPID FEED SPEED m/min 36 36
SPINDLE SPEED rpm 4500 4500
CUTTING FEED SPEED m/min 1-8 1-8
Tools Tpye Servo tool Servo tool
TOOLS MAGAZINE CAPACITY ea 12 12
Tool indexing time sec/step 0.35(0.8) 0.35(0.8)
External round tool size mm 25 25
Maximum boring tool diameter mm ∅40 ∅41
Milling shaft power kW 4.9Kw
Milling spindle speed rpm 4000
Type ot tailstock MT4 MT4
tailstock movement speed m/min 10 10
Maximum movement of tailstock mm 530 530
Thrust adjustment range kgf 20-350 20-350
System coolant capacity L 180 180
Power source KVA 20 30
Power source request V 3∅380V+10%~-15% 3∅380V+10%~-15%
Control system 828D240 828D240
MACHINE DIMENSION mm 2530*2020*2060 2530*2020*2060
MACHINE WEIGHT kg 4600 4600
