HMultipurpose 5m Vertical CNC Lathes Machine Practical CKNC6163
HMultipurpose 5m Vertical CNC Lathes Machine Practical CKNC6163
Specifications
Brand Name :
Li Zhun
Model Number :
CKNC-6163
Certification :
SGS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10000 per year
Delivery Time :
45-60 Work Days
Packaging Details :
Wooden Box
Type :
Vertical
Condition :
New
Warranty :
1 Year
Metre :
5m
Net weight :
5000kg
Outline size :
1200*1500*2400
Description

High Speed 5metre CNC Vertical CNC Lathes CNC Machine CKNC6163

Product features

It is suitable for processing various heavy and complicated shaft and sleeve disk parts, such as turning internal and external cylindrical surface, conical surface, circular arc surface, end face, groove cutting, chamfering, thread turning, etc.

Bed body, bed foot, headstock assembly, tailstock assembly, bed saddle, sliding plate, X/Z direction motor base, slide plate base, X/Z direction nut, Z backward bracket, screw rod protective cover, bed saddle protective cover lubricating oil circuit, encoder interface, chuck transition plate, scrap iron plate, main motor base plate, packing list, simple packaging base plate, belt pulley, belt, scrap leather, tool box and a set of common tools.

Main Parameters

ITEM MODELS→ CKNC-6163
maximum turning diameter on the bed mm ∅630
maximum turning diameter on board mm ∅350
maximum turrning length on the chuck mm 850/1350/1850
nominllength mm 1000/1500/2000
maximum diameter of the bar passing the spindle mm ∅100
maximum stroke of the x axis (trsnsverse) mm 400
stucture type Split bed foot
maximum stroke of the z axis(longitudinal) mm 1000/1500/2000
guide rail width MT No. 550
apex diasance from the spindle to the tailsock mm 1000/1500/2000
spimdle head type mm C-11
spindle head taper type metric system 1:20
spindle bore diameter MT No. ∅ 105
X /Z axis screw rod type r/min 3205/5010
diameter and stroke of tailstock sleeve mm ∅100 250
outline size(long) mm 3200/3700/4200
outline size(wide*keight) mm 1200*1500
machine weight kg 4000/4500/5000


Product Details

HMultipurpose 5m Vertical CNC Lathes Machine Practical CKNC6163

FAQ

1. Is it all right to make customer's own brand name?

A: yes. we are available with OEM

2. Are you a manufactuer or trading company?

A:We are the manufacturer

3. Can you do the design for us?

A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?

A: FOB shenzhen.

5. What's your payment term?

A: T/T OR L/C at sight.
