Tjr Tilting Index 5 Axis CNC Machine Rotary Table FHR(S)-255C

Product Introduction

FHR(s)-255C Five-axis machining centers can also reduce benchmark conversion and improve machining accuracy. In actual machining, only one clamping is required, making it easier to ensure machining accuracy. At the same time, due to the shortening of the process chain and the reduction in the number of equipment, the number of fixtures, workshop area, and equipment maintenance costs of the five-axis machining center have also decreased. This means that you can use fewer fixtures, less plant area, and maintenance costs to achieve more efficient and high-quality processing!

Product parameters

Item Unit FHR(s)-255C /255CL
Table Diameter mm Ø 255

Diameter of center hole on disk surface

 mm Ø 110
Inner Diameter of Mandrel Sleeve mm Ø 80H7
Diameter of Center Through Hole mm Ø 80
Table Height (Horizontal) mm 290
Table T-slot Width mm 12H7
Guide Block Width mm 18h7
Axis - Rotary axis Tilt axis±110º
Transmission Mechanism deg. 0.001 0.001

segmentation precision

 sec. 15 60 *¹
Repeatability sec. 6 8
Clamping System kg/cm2 35 35
Clamping Torque kg-m 70 140
Servo Motor Model FANUC

Axis taper/Straight axis

 αiF4 / αiF8 / αiS12 / ßiS8(Type) αiF8 / αiS12 / ßiS12(Type)
Mitsubishi Straight axis HG/HF-104 HG/HF-154
Speed Reduction Ratio - 0.125 0.125
Max. Rotation Rate of Table
(Calculate with FANUC α Motor)		 r.p.m 33.3 * (25) 16.6 * (11.1)
Allowable Inertia Load Capacity (Horizontal) kg.cm.sec2 8.13
Allowable Workpiece Load (dynamic) 0º Horizontal kg 100
0º~90º Tilt kg 75
Allowable Load
(with clamping)		 F kgf 1500
FxL kgf.m 140
FxL kgf.m 70
(Rotary axis)Strength of Roller Gear Cam kg.m 55 *(31)
Net Weight (servo motor excluded) kg 296(Ø255C) / 312(Ø255CL)
