Specifications
Model Number :
VMC1160
MOQ :
1
Packaging Details :
plywood case
Payment Terms :
T/T
Z axis travel :
600mm
Price :
18500-24500
Table size :
1200*600mm
Delivery Time :
20 working days
Y axis travel :
600mm
Spindle taper :
BT40
Brand Name :
Matsumoto
X axis travel :
1100mm
Certification :
CE
Place of Origin :
China
Description

4 axis CNC Milling Machine VMC1160 Automatic Heavy Duty Vertical Metal Milling Machine


Description:

VMC1160 is a high-performance 3-axis vertical CNC machining center. The base, worktable, column, saddle and spindle box are cast from premium high-strength cast iron via resin sand casting, delivering outstanding structural strength, rigidity and long-term operational stability.


It adopts high-rigidity Taiwan-made BT40 spindle with grease lubrication, offering continuous, stable and reliable lubrication protection for spindle bearings during long-hour heavy cutting.


Equipped with precision linear guides and pre-stretched ball screws, it ensures excellent positioning & repeat positioning accuracy. Optional automatic tool changer, 4th/5th axis and mainstream CNC systems.


Specifications Units VMC1160
Table size mm 1200*600
Max.table load kg 800
T slot / 5-18*100
X axis travel mm 1100
Y axis travel mm 600
Z axis travel mm 600
Distance between spindle center and column surface mm 600
Distance between spindle nose and table surface mm 120-720
Max. spindle speed r/min 8000(10000 optional)
Spindle taper - BT40
Spindle drive type - Belt drive
spindle motor power kw 11
X/Y/Z axis rapid traverse m/min 36/36/24
X/Y/Z guide rail form / 3 axis linear guide rail
Automatic tools changer - 24 arm ATC
Max.tool weight kg 7
Tools Diameter/Length mm 78/300
Tool change time s 7/2.5
Position accuracy mm ±0.005
Repeat positioning accuracy mm ±0.003
Machine dimension mm 3400*2480*2960
Machine weight kg 7300
