Specifications
Max. Table load :
1000kg
Model Number :
VMC1270
Table size(L*W) :
1300*700mm
Brand Name :
Matsumoto
Max. Spindle speed :
12000rpm
MOQ :
1
Packaging Details :
plywood case
Payment Terms :
T/T
Delivery Time :
30 working days
Spindle taper :
BT40
Price :
28000-32000
X/Y/Z axis travel :
1200/700/600mm
Certification :
CE
Spindle center to column surface distance :
720mm
Place of Origin :
China
Description

VMC1270 3 Axis CNC Machining Center High Precision Milling Machine Supplier


Description:

The VMC1270 vertical machining center is a heavy-duty 3-axis CNC milling machine with large travel, high rigidity cast iron body and roller linear guides. Equipped with BT40 spindle, it supports optional 4th/5th axis rotary table, compatible with Fanuc, Mitsubishi ,GSK control systems. High precision, stable cutting performance, low vibration and long service life. CE certified, widely used for heavy metal cutting, mold making and batch precision component processing. Adopts direct drive spindle for fast speed and efficient machining, ideal for medium & large size workpiece production.


VMC1270 heavy-duty vertical CNC machining center with roller linear guides, BT40 spindle & optional 4/5 axis. CE certified, Fanuc/Mitsubishi system for mold, auto & metal parts processing. Direct factory supply, competitive price.


PROJECT
UNIT
VMC1270
VMC1580
Table size(L*W)
mm
1300*700
1700*800
Max. Table load
kg
1000
1500
X/Y/Z axis travel
mm
1200/700/600
1500/800/700
Spindle center to column surface distance
mm
720
810
Spindle nose to table
mm
120-797
170-840
Max. Feed speed(X/Y/Z)
mm/min
1-20000
1-5000
Max. Moving speed(X/Y/Z)
m/min
24/24/20
15/15/12
Max. Spindle speed
r/min
12000
6000
Spindle taper
/
BT40
BT50
Spindle power
kw
11/15
15/18.5
T-slot(width*number*pitch)
mm
18*7-100
22*5-135
Positioning accuracy
mm
±0.010
±0.01
Repeat positioning accuracy
mm
±0.006
±0.0075
Tool library capacity
/
24(Disc type)
Max. Tool weight
kg
8
15
Max. Tool diameter
mm
120
150
Weight
kg
7300
13000
Dimension(L*W*H)
mm
3150*2430*2400
4300*3200*2100
