VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre
Specifications
Delivery Time :
20 working days
Max.table load :
800kg
Model Number :
VMC855
MOQ :
1
Packaging Details :
plywood case
Payment Terms :
T/T
T slot :
5-18*90
Price :
15500-20500
X/Y/Z axis travel :
800/550/550mm
Certification :
CE
Brand Name :
Matsumoto
Place of Origin :
China
Table size :
1000*550mm
Description

VMC855 Vertical Machining Center CNC Controller CNC Milling Machine 3 Axis Automatic Machining Centre


Specifications Unit VMC855
Table size mm 1000*550
Max.table load kg 800
T slot
5-18*90
X axis travel mm 800
Y axis travel mm 550
Z axis travel mm 550
Distance between spindle center and column surface mm 550
Distance between spindle center and column surface mm 120-670
Max. spindle speed r/min 8000(10000 optional)
Spindle taper / BT40
Spindle drive type / Belt drive
spindle motor power kw 7.5
X/Y/Z axis rapid traverse m/min 36/36/24
X/Y/Z guide rail form / 3 axis linear guide rail
Automatic tools changer
24 arm ATC
Max.tool weight kg 7
Tools Diameter/Length mm 78/300
Tool change time s 7/2.5
Position accuracy mm ±0.005
Repeat positioning accuracy mm ±0.003
Machine dimension mm 2750*2300*2600
Machine weight kg 5800
