IP68 Metric Thread Nylon Cable Gland Waterproof Cordgrips with PA66 Material for Secure Cable Protection
IP68 Metric Thread Nylon Cable Gland Waterproof Cordgrips with PA66 Material for Secure Cable Protection
IP68 Metric Thread Nylon Cable Gland Waterproof Cordgrips with PA66 Material for Secure Cable Protection
IP68 Metric Thread Nylon Cable Gland Waterproof Cordgrips with PA66 Material for Secure Cable Protection
Specifications
Working temperature :
-20°C to 80°C in dynamic state,-40℃~100℃
Protection level :
IP68,IP67-5,IP68-10bar pressure
Cable range :
3-6.5mm to 37-44mm
Brand Name :
LKS
Certification :
RoHS,SGS,CE,ISO9001
Place of Origin :
China
MOQ :
10000pcs
Payment Terms :
L/C,T/T
Supply Ability :
100000pcs per day
Delivery Time :
5days
Packaging Details :
polybag
Spanner size :
18/17mm to 75/68mm
Thread type :
Metric PG NPT G Standard
Material :
PA6/PP, Nylon PA66
Description

Technical Information:

  • Model: METRIC Type
  • Material: PA6/PP.
  • Size: M12 to M66.
  • Color:White/Grey/Black/Red or OEM Color.
  • Protection Level: IP68.
  • Weather Strip: NBR, EPDM.
  • Working temperature:-40℃ to 100℃,short time to 120℃.
  • Packing:100pcs/bag,50pcs/bag,20pcs/bag,5pcs/bag.
  • Port: Shanghai/Ningbo.

Description:

  • Thread: Metric
  • Materials:Part A.C.F is made of UL approved nylon PA66(fire rating UL94V-2),part B.D butadiene rubber(NBR)or EPDM.
  • Protection Degree:IP68(within fasteing range,O type was her will be used in tightening part)
  • Working Temperature:-40℃ to 100℃ in static state,instantaneous heat resistance up to 120℃; -20℃ to 80℃ in dynamic state,instantaneous heat resistance up to 100℃.
  • Product Features:Wide rang for fastening cables,strong tensile strength,waterproof,dustproof,resistant to acid and alkali,alcohol,grease and general solvents.
  • Color:Light grey(RAL7035),black(RAL9005),other color can be customized according to request.
Model Cable Range(mm) Thread O.D AG()mm Thread Length GL(mm) Spanner Size(mm)
M12×1.5 3-6.5 12 8 18/17
M12×1.5 2-5 12 8 18/17
M12×1.5 4-8 12 8 18/19
M12×1.5 2-6 12 8 18/19
M16×1.5 4-8 16 8 22/19
M16×1.5 2-6 16 8 22/19
M16×1.5 5-10 16 9 22/22
M16×1.5 3-7 16 9 22/22
M18×1.5 5-10 18 9 24/22
M18×1.5 3-7 18 9 24/22
M20×1.5 6-12 20 10 27/24
M20×1.5 5-9 20 10 27/24
M20×1.5 10-14 20 10 27/27
M20×1.5 8-12 20 10 27/27
M22×1.5 10-14 22 10 30/27
M22×1.5 8-12 22 10 30/27
M24×1.5 12-16 24 10 30/27
M24×1.5 10-14 24 10 30/27
M25×1.5 13-18 25 10 33/33
M25×1.5 9-16 25 10 33/33
M27×1.5 13-18 27 10 36/33
M27×1.5 9-16 27 10 36/33
M30×1.5 16-20 30 11 37/36
M30×1.5 13-18 30 11 37/36
M32×1.5 16-20 32 11 40/35
M32×1.5 13-18 32 11 40/35
M32×1.5 18-25 32 13 40/42
M32×1.5 13-20 32 13 40/42
M36×1.5 18-25 36 12 46/42
M36×1.5 13-20 36 12 46/42
M40×1.5 22-32 40 15 50/52
M40×1.5 20-26 40 15 50/52
M50×1.5 32-40 50 15 62/60
M50×1.5 25-31 50 15 62/60
M63×1.5 37-44 63 15 75/68
M63×1.5 29-35 63 15 75/68
