Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Cartex-ABPN EagleBurgmann Cartridge Mechanical Seal for ANSI Process Pumps
Specifications
Delivery Time :
15 working days
Seal face :
Silicon carbide (Q1), Carbon graphite resin impregnated (B), Tungsten carbide (U2)
Springs :
Hastelloy® C-4 (M)
Model Number :
Cartex-ABPN
Shaft diameter :
d1 = 1.000" ... 3.750"
MOQ :
1pc
Packaging Details :
Carton
Sliding face material combination Q1Q1 or U2Q1 Pressure :
p1 = 12 bar (174 PSI)
Seat :
Silicon carbide (Q1)
Supply Ability :
1000000/Month
Sliding face material combination Q1Q1 or U2Q1 Speed :
10 m/s (33 ft/s)
Metal parts :
CrNiMo steel (G)
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Sliding face material combination BQ1 Speed :
16 m/s (52 ft/s)
Certification :
ISO9001
Temperature :
t= -40 °C ... 220 °C (-40 °F ... 428 °F)
Brand Name :
BESTSEAL
Model NO. :
Cartex-ABPN
Place of Origin :
CHINA
Sliding face material combination BQ1 Pressure :
p1 = 25 bar (363 PSI)
Secondary seals :
FKM (V), EPDM (E), FFKM (K), Perflourocarbon rubber/PTFE (U1)
Description

Cartex-ABPN EagleBurgmann Single Cartridge Mechanical Seal for ANSI Process Pumps

  • Single seal
  • big bore (Cartex-ABPN) seal chambers
  • Cartridge
  • Balanced
  • Independent of direction of rotation
  • Single seals with flush (-ABPN)

Advantages

  • Ideal for use in ANSI process pumps
  • Universal applicable for packings conversions, retrofits or original equipment
  • Seal for standardizations
  • No dimensional modification of the seal chamber necessary, small radial installation height
  • No damage of the shaft by dynamically loaded O-Ring
  • Extended service life
  • Installation faults are avoided, cost-effective
  • No damage caused by dirt entered during assembly
  • Straightforward and easy installation due to pre-assembled unit (reduced down-times)

Operating Limits

  • Shaft diameter: d1 = 1.000" ... 3.750"
  • Other sizes on request
  • Temperature: t = -40°C...+220°C (-40°F... +428°F)
  • Sliding Face Material Combination BQ1:
  • Pressure: p₁ = 25 bar (363 PSI)
  • Speed: = 16 m/s (52 ft/s)
  • Sliding Face Material Combination Q1Q1 or U2Q1:
  • Pressure: p₁ = 12 bar (175 PSI)
  • Speed: = 10m/s (33ft/s)
  • Permissible axial movement: ± 1.0 mm, d₁ ≥ 75mm ± 1.5mm

Materials

  • Seal face: Silicon carbide (Q1), Carbon graphite resin impregnated (B), Tungsten carbide (U2)
  • Seat: Silicon carbide (Q1)
  • Secondary seals: FKM (V), EPDM (E), FFKM (K), Perflourocarbon rubber/PTFE (U1)
  • Springs: Hastelloy® C-4 (M)
  • Metal parts: CrNiMo steel (G)

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress
  • BESTSEAL Cartridge Mechanical Seals
  • Your Fast-Track Alternative to EagleBurgmann Cartex-ABPN
  • Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
