Precision Cylindrical Lens OEM Cylinder Lens With K9 B 270/JGS 2 Material And 400 - 700nm AR Coating

Specifications

Material :

K9 B 270,JGS 2

Center thickness :

±0.1mm

Clear aperture :

>90%

Surface quality :

60-40

Model Number :

Brand Name :

Non

Place of Origin :

Guangdong, China

MOQ :

1000

Price :

Dimensional tolerance :

+0/-0.2m

Focal length :

±2%@10.6unm

Name :

Cylindrical Lens

Description

Precision Cylindrical Lens with K9 B 270/JGS 2 Material and 400-700nm AR Coating for Optical Applications

Product Overview

Cylindrical Lenses are ideal for one-dimensional magnification applications. Unlike spherical lenses that act symmetrically on incoming light in both directions, cylinder lenses act on incoming light in only one direction. Typical applications include shaping anamorphic beams with pairs of cylinder lenses, collimating and rounding laser diode outputs, and focusing diverging beams onto detector arrays.

To minimize spherical aberration, collimated sources should be directed from the curved face when focusing beams as lines, and line sources should be directed from the flat face when collimating line sources.

Technical Specifications

Parameter	Specification
Product Name	Cylinder lenses
Material	K9 B 270, JGS 2
Focal Length (f)	±2%@10.6μm
Dimensional Tolerances	+0/-0.2mm
Center Thickness Tolerance	3'
Power	3
Irregularity	0.5
Surface Quality	60-40
Clear Aperture	>90%
Coating	400-700nm AR Coating

Typical Applications & Dimensions

Size	Image Focal Length	Back Focal Length	Center Thickness	Edge Thickness	Radius of Curvature
12.5×25.0mm	12.5mm	10.37mm	3.8mm	1.55mm	9.81mm
12.5×25.0mm	15.0mm	13.21mm	3.2mm	1.40mm	11.77mm
12.5×25.0mm	20.0mm	17.63mm	3.6mm	1.50mm	10.34mm
12.5×25.0mm	25.0mm	23.02mm	3.0mm	1.39mm	12.92mm
12.5×25.0mm	50.0mm	48.68mm	2.0mm	1.23mm	25.84mm
12.5×25.0mm	75.0mm	73.68mm	2.0mm	1.49mm	38.76mm
12.5×25.0mm	100.0mm	98.66mm	2.0mm	1.62mm	51.68mm
12.5×25.0mm	150.0mm	148.68mm	2.0mm	1.75mm	77.52mm

Spectral Performance

Product Gallery

Manufacturing Process
