30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
30KW Belt driven air-cooling oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGFD-30B C
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
9200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.8-1.5Bar
Cooling type :
Air cooling
Driven type :
Belt driven
Description
The Marathoner of Industrial Power: AIRERA 30kW Belt-Driven Air-Cooled Oil-Injected Screw Compressor

The AIRERA 30kW Series seamlessly integrates advanced air-cooling technology with high-precision belt drive systems, specifically engineered for factory environments that demand consistent stability and effortless maintenance. By leveraging cutting-edge oil-injection cooling, the unit maintains optimal internal temperatures even under extreme workloads, ensuring a relentless power output while significantly reducing long-term wear and tear costs. As a flagship of the AIRERA lineup, it combines a rugged mechanical structure with superior energy efficiency to deliver a 24/7 uninterrupted supply of clean compressed air, serving as the reliable industrial heart that drives your production line’s growth and efficiency.

Advantages of AGFD Oil-Inject Air Screw Compressor:

  • Extraordinary cooling system, 20-30% cooling performance than the old models, and friendly to do maintain job to cooler and cooling fan

30KW Belt driven air-cooling oil inject screw compressor

  • Advanced Intelligent colorful touchable control system for simple& easy operation

    30KW Belt driven air-cooling oil inject screw compressor


  • Unique driving guard system to increase the lifespan of driving system


Technical Specifications - 30KW Air Cooling Compressor
30KW Air Cooling Compressor Parameters
ITEM UNIT MODEL AGFD-30
Free air delivery m³/min 5-3.25
Max. working pressure MPa 0.8-1.5
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Belt driven
Inlet status - Temperature ℃ ≤55
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤1
Drive rotor speed rpm 4030~2950
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 9200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.88 ~ 1.6
Lubricating water volume L 30
Compressed air outlet connection
G1
Dimension - L mm 1200
Dimension - W mm 950
Dimension - H mm 1300
Net Weight kg 680
Motor - Model
Y2180L2-2
Motor - Speed rpm 2950
Motor - Rated Power KW 30
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
ʏ-Δ starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 50(Special on request)
Motor - Rated current A 56.9
Motor - Weight of motor kg 232
30KW Belt driven air-cooling oil inject screw compressor
AIRERA 30kW Screw Air Compressor: Frequently Asked Questions (FAQ)
How does a 20-30% improvement in cooling performance benefit my production?
Heat is the enemy of efficiency. The redesigned AIRERA cooling system increases thermal dissipation by up to 30% compared to legacy models. This ensures the unit maintains an optimal constant temperature even in high-ambient summer conditions or poorly ventilated workshops, preventing high-temperature trips and protecting the lubricating oil from premature emulsification and degradation.
Is the advanced smart color touch control system difficult to operate?
On the contrary, it is designed for "Simplified Operation with Professional Management." The intuitive full-color interface provides real-time visualization of pressure, temperature, and run-time data. With built-in smart alarms and automated maintenance reminders, it allows even non-technical staff to manage the equipment effectively, drastically reducing labor management costs.
How much can I save with the IE3 high-efficiency motor and 1.2 Service Factor (SF)?

Our motors improve efficiency by approximately 15%. With an SF of 1.2 for superior overload capacity and an IP55 rating for dust/water protection, these motors maintain peak performance in harsh industrial environments. Based on 8,000 annual operating hours, the electricity savings alone can often cover your entire annual maintenance budget—true "Green Production" in action.
