200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
200KW 37.5~25m3/min Oil Inject Screw Compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGCD-200D C
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
19200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.7-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Free air delivery :
37.5~25m3/min
Description

AIRERA 200kW Industrial Oil-Injected Screw Compressor: The Benchmark for High-Capacity Energy Efficiency

The AIRERA 200kW Series is the ultimate power core tailored for large-scale manufacturing enterprises that demand exceptional productivity. With a versatile capacity range of 25 to 37.5 m³/min, this series is engineered to provide stable, powerful compressed air with superior specific power output. AIRERA is committed to minimizing the energy cost per cubic meter of compressed air, even under the most demanding heavy-duty operating conditions.

Key System Advantages
Electric motor

Only electric motors from well-known manufacturers of protection class IP55/IE3&4 are used. As a standard, the drive motors are monitored both thermally (via the thermistor of the motor) as well as electronically (overload protection via the frequency inverter).

200KW 37.5~25m3/min Oil Inject Screw Compressor

Oil circuit

The amount of oil in the units is determined in such a way as to extend the oil change intervals (depending on ambient conditions). An oil level sensor is integrated as standard and is read by the controller. All the units in this series have a horizontal oil separation vessel in which the oil is separated from the compressed air highly efficiently at low speeds.

200KW 37.5~25m3/min Oil Inject Screw Compressor

Drives and electrics

The almost loss-free power transmission guarantees reliable, high-performance compressor operation. The regular maintenance requirement is reduced to lubrication of the motor. All the electronic components are brand products of leading manufacturers.

200KW 37.5~25m3/min Oil Inject Screw Compressor
Technical Specifications - 200kW Air Cooling Compressor
ITEM UNIT MODEL AGCD-200
Free air delivery m³/min 37.5~25
Max. working pressure MPa 0.7~1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤82
Residual oil content ppm ≤2
Drive rotor speed rpm 2980
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 19200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77 ~ 1.43
Lubricating oil volume L 110
Compressed air outlet connection
DN80
Dimension - L mm 3150
Dimension - W mm 1800
Dimension - H mm 1800
Net Weight kg 3300
Motor - Model
Y2355L1-2
Motor - Speed rpm 2980
Motor - Rated Power KW 200
Motor - Service factor
1.2
Motor - Efficiency
IP55
Motor - Startup mode
Y-Δ starting
Motor - Voltage V 380 (Special on request)
Motor - Frequency Hz 50 (Special on request)
Motor - Rated current A 405
Motor - Weight of motor kg 1610
200KW 37.5~25m3/min Oil Inject Screw Compressor
Frequently Asked Questions
Q1: How does the 200kW unit ensure stability with such a high flow rate (37.5m³/min)?
A: High capacity means higher thermal loads. The AIRERA 200kW series utilizes a heavy-duty, oversized rotor air-end, which operates at a much lower RPM than the industry average, effectively reducing mechanical wear and heat generation. Additionally, we’ve integrated an enhanced cooling system and a reinforced chassis to ensure minimal vibration and constant discharge temperatures during 24/7 continuous full-load operation.
Q2: For a 200kW "energy-intensive" unit, what specific measures does AIRERA take to save energy?
A: Electricity costs for 200kW units are significant. We address this in two ways:

  • Specific Power Optimization: Through our high-precision rotor profiles, we produce more air per kilowatt (up to 37.5m³/min), directly lowering unit energy consumption.

  • VSD Constant Pressure Technology: Our smart VFD control dynamically adjusts motor speed based on real-time demand. This eliminates the massive energy waste caused by frequent "load/unload" cycles in large units, resulting in total energy savings of over 30%.
