200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
200KW Direct driven air-cooling oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGFD-185B C
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
19200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.8-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Description
AIRERA 200KW Direct-Drive Air-Cooling Oil-Injected Screw Compressor: High-Efficiency Performance for Heavy-Duty Industrial Demands

The AIRERA 200KW direct-drive oil-injected screw compressor represents the pinnacle of industrial efficiency, featuring a high-precision 1:1 direct-drive transmission that eliminates mechanical power loss and maintenance issues common in belt-driven models. This robust system integrates an advanced air-cooling setup with an oversized radiator to ensure peak thermal stability during continuous high-load operations, while the specialized oil-injection technology provides superior lubrication and internal sealing for maximum durability. Designed for large-scale facilities requiring a stable and high-volume air supply, this compressor incorporates AIRERA’s signature intelligent control system to monitor real-time performance and optimize energy consumption, effectively reducing the total cost of ownership while delivering reliable, clean, and powerful compressed air to sustain your most demanding production lines without interruption.

Advantages of AGFD Oil-Inject Air Screw Compressor:

  • Advanced Intelligent colorful touchable control system for simple& easy operation

200KW Direct driven air-cooling oil inject screw compressor

  • Unique driving guard system to increase the lifespan of driving system

    200KW Direct driven air-cooling oil inject screw compressor


  • Pick-up French Schneider white-color high-end contractor to keep more durable in extreme environment

200KW Direct driven air-cooling oil inject screw compressor


Technical Specifications - 200KW Air Cooling Compressor
200KW Air Cooling Compressor Parameters
ITEM UNIT MODEL AGFD-200
Free air delivery m³/min 36-25
Max. working pressure MPa 0.8-1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤79
Residual oil content ppm ≤2
Drive rotor speed rpm 2980
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 19200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.88 ~ 1.43
Lubricating water volume L 90
Compressed air outlet connection
DN100
Dimension - L mm 2550
Dimension - W mm 1750
Dimension - H mm 1960
Net Weight kg 2680
Motor - Model
Y2315L2-2
Motor - Speed rpm 3580
Motor - Rated Power KW 200
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
ʏ-Δ starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 50(Special on request)
Motor - Rated current A 365
Motor - Weight of motor kg 1410
200KW Direct driven air-cooling oil inject screw compressor
AIRERA 200kW Screw Air Compressor: Frequently Asked Questions (FAQ)
Is the maintenance cost high for this specific model?
Not at all. Due to the direct-drive structure, there is no need to regularly replace or adjust belts. Furthermore, AIRERA has optimized the internal layout so that the oil-air separator, oil filter, and air filter are all easily accessible. Combined with intelligent maintenance alerts, this effectively prevents expensive repair costs caused by overdue servicing.
How does AIRERA solve the heat dissipation challenges common in high-power compressors?
To handle the high thermal output of the 200kW range, we utilize an enhanced air-cooling system equipped with a high-power, low-noise axial fan and a thickened all-aluminum plate-fin radiator. This combination ensures powerful heat exchange capacity, effectively preventing high-temperature shutdowns and guaranteeing that production lines remain operational even in peak summer conditions.
What is the long-term operational stability of this compressor?

The AIRERA 200kW model features heavy-duty bearings and high-precision screw rotors, complemented by a precise oil-injection cooling system to ensure stable discharge pressure during 24-hour continuous operation. Every unit undergoes rigorous full-load testing before leaving the factory, aiming to provide the most reliable power core for large-scale industrial facilities.
