40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
Specifications
Brand Name :
AIRERA
Model Number :
OWFD-30D A/B/C VP
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
8800
Application :
Medical Equipments,bus,medical dental,General Industry,For airbrush and mini spray gun
Working Pressure :
0.7-1.0MPa
Cooling type :
Air cooling
Driven type :
Direct driven
Lubrication style :
Oil-free
Motor power :
30KW
Description
AIRERA 40HP VSD Series: High-Capacity Power with Absolute Purity

The AIRERA 40HP (30kW) VSD Direct-Driven Oil-Free Air Compressor represents the ultimate solution for large-scale industrial operations demanding high-volume, sterile air. By integrating Variable Speed Drive (VSD) technology, this system intelligently eliminates idle energy consumption, reducing overhead costs by matching output to demand in real-time. The Direct-Driven architecture maximizes torque efficiency while removing the maintenance burden of traditional belt systems.

Equipped with a robust Air Cooling system, it ensures continuous thermal stability for 24/7 duty cycles. The 100% Oil-Free design guarantees ISO Class 0 air quality, making it a critical asset for the food processing, healthcare sector, and precision electronics industries where zero contamination is a necessity.

Advantages of OGFD Air Screw Compressor:

  • Constant Voltage and Power Saving
The pressure comparison shown in the figure is in the operation of standard air compressor and the VFD air compressor. In standard air compressor, the loading and unloading is frequently changed between the sufficient pressure and pressure more than 1.5bar, which costs 10.5% of power consumption(more 7% of power is consumed when each 1bar is increased )compare with the inverter control. In addition, 45% of idle power energy is consumed in standby status of zero air supply in the unloading. Therefore, air supply inconstant pressure is not only very low power consumption, but also avoids the reduction of service life of the unit caused by the control of loading and unloading and the adverse factors of unstable pressure brought to the production of the enterprise.
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
  • Imported softeners

Used to remove scale from cooling water and effectively prevent the precipitation of impurities, ensuring unobstructed compressor piping. It has a maximum service life of 3 years.


40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor

  • Air filter

Features a pre-filter with a pleated filter element, offering low pressure drop, durability, and the ability to remove 99.99% of airborne contaminants.

40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor


Technical Specifications - 30KW Air Cooling Compressor
30KW Air Cooling Compressor Parameters
ITEM UNIT MODEL OWFD-30D A/B/C VP
Free air delivery m³/min 3.1-5.2|2.8-4.7|2.5-4.3
Max. working pressure MPa 0.7-1.0
Compressor type
Oil-free screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ 2-40
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤64
Drive rotor speed rpm 3000
Compressed air outlet temperature ℃ Ambient temperature＋20
Cooling air flow m³/hr 8800
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77 ~ 1.10
Lubricating water volume L 40
Compressed air outlet connection
G1-1/2
Dimension - L mm 1920
Dimension - W mm 1170
Dimension - H mm 1320
Net Weight kg 1120
Motor - Model
TYCP160M2-8
Motor - Speed rpm 3000
Motor - Rated Power KW 30
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE5
Motor - Startup mode
Frequency conversion starting
Motor - Voltage V 400(Special on request)
Motor - Frequency Hz 50-200(Special on request)
Motor - Rated current A 52
Motor - Weight of motor kg 120
40HP VSD Direct-driven Air Cooling Oil-free Industrial Air Compressor
AIRERA 30kW Screw Air Compressor: Frequently Asked Questions (FAQ)
Does Variable Speed Drive (VSD) technology really reduce my electricity bills significantly?
Yes. Traditional compressors enter an "unloaded" idling state after reaching set pressure, wasting about 30% of energy. The AIRERA VSD series adjusts motor speed in real-time to perfectly match power output with actual air demand, eliminating idle waste and typically saving 25%-35% on energy costs.
How does the smart controller impact the daily operation of this compressor?
The integrated intelligent PLC controller acts as the brain of the machine, monitoring pressure and temperature in real-time. It automatically adjusts the operation to match actual air demand, preventing excessive idling and reducing energy consumption while protecting the motor from electrical overloads.
What are the cost benefits of choosing an oil-free system over an oil-injected one?

While the initial investment may be higher, the long-term savings are significant. You eliminate costs for oil, oil filters, and oil-separator replacements. Furthermore, you avoid the potential costs of damaged products caused by oil contamination and the legal expenses of hazardous waste oil disposal.
