Specifications
Brand Name :
AFP
Model Number :
Gloss Laminating Film
Certification :
FDA, ROHS, EN71
Place of Origin :
Fujian, China
MOQ :
2 Tons (Mixed roll widths accepted)
Price :
USD1860.00/Ton ~ USD2388.00/Ton
Payment Terms :
T/T, L/C
Supply Ability :
850 Tons per month
Delivery Time :
15 - 25 working days
Packaging Details :
1-One roll one carton with plastic caps protection; 2-Tens of rolls a pallet; 3-Ten pallets a 20FCL
Name :
Gloss Laminating Film
Material :
BOPP/PET+ EVA
Type :
Gloss
Softness :
Soft
Thickness :
from 15micron to 30mic
Transparent :
Transparency or Opaque
Roll Size :
750mm*150m, 445mm*2000m, 650mm*3000m, etc.
Corona Treatment :
Double sides, over 38 dynes
Paper Core :
1inch (25.4mm), 2.3inch (58mm), 3inch (76mm),
Laminator :
Thermal Laminating Machine
Laminating Speed :
10-60m/min
Description
15micron - 30micron Soft Gloss Laminating Film With Single/Double Corona Treatment
Lustre Finish Glossy Thermal Lamination Film

As a professional supplier of Thermal Lamination Film, we produce premium lustre finish glossy thermal lamination films that provide excellent glossy finishes to various substrates including paper and paperboard. These films are suitable for offset printing, screen printing, flexographic printing, rotogravure printing, and digital printing applications.

Compared with regular substrates, laminated paper exhibits enhanced shine and gloss while gaining waterproof properties.

15micron - 30mic Soft Gloss Laminating Film With Single / Double Corona Treatment
Product Technical Specifications
BOPP Gloss Laminating Film
Parameter Specification
Material BOPP (Biaxially Oriented Polypropylene) Film
Thickness 15micron to 30micron
Adhesion EVA (Ethyl Vinyl Acetate)
Roll Width 180mm to 1880mm
Corona Treatment Single or Double
Roll Length 300m to 4000m
Surface Tension Over 38 dynes
Joint ≤1
Shelf Life 9 months
Core Size 1inch (25.4mm), 3inch (76.2mm)
MOQ 2 tons (mixed width available: 500mm, 600mm, 700mm, etc.)
Operation Guidance - BOPP Film
Parameter Specification
Compound Temperature 85℃ - 105℃ (185℉ - 221℉)
Compound Pressure 10-18 mpa
Compound Speed 10-60m/min
PET Gloss Laminating Film
Parameter Specification
Material PET (Polyester) Film
Thickness 12micron to 350micron
Adhesion EVA (Ethyl Vinyl Acetate)
Roll Width 180mm to 1400mm
Corona Treatment Single or Double
Roll Length 50m to 3000m
Surface Tension Over 42 dynes
Joint ≤1
Shelf Life 12 months
Core Size 1inch (25.4mm), 2.3inch (58mm), 3inch (76.2mm)
MOQ 2 tons (mixed width available: 500mm, 600mm, 700mm, etc.)
Operation Guidance - PET Film
Parameter Specification
Compound Temperature 90℃ - 150℃ (194℉ - 302℉)
Compound Pressure 10-18 mpa
Compound Speed 10-50m/min
15micron - 30mic Soft Gloss Laminating Film With Single / Double Corona Treatment
What is Gloss Laminating Film?

Gloss laminating film is manufactured using multi extrusion coating lines and consists of two primary layers: a plastic film base (primarily BOPP or PET) and an adhesive EVA glue layer. Also known as dry, hot, or heat laminating film, this product provides superior surface protection and enhancement.

15micron - 30mic Soft Gloss Laminating Film With Single / Double Corona Treatment
Applications

Printing houses commonly use BOPP gloss laminating film rolls for commercial and educational printing applications, as well as large format graphic arts. The transparent film lamination, available in bright/shine/glossy or matte/dull finishes, is heated to provide protective coating on paper covers. This process is often referred to as paper lamination film application using heated EVA adhesive glue on paper substrates.

Specific Applications Include:
  • Textbook covers
  • Brochures
  • Leaflets
  • Sweet boxes and diaries
  • Shopping bags
  • Cosmetics boxes
15micron - 30mic Soft Gloss Laminating Film With Single / Double Corona Treatment
Packaging & Shipping
  • One roll of gloss laminating film per carton
  • Tens of rolls per pallet
  • 10 to 12 pallets loaded into 1*20FCL (approximately 13 metric tons)
  • 20 to 22 pallets loaded into a 40-foot container (approximately 25 metric tons)
  • Seaports: Xiamen, Shanghai, Ningbo
15micron - 30mic Soft Gloss Laminating Film With Single / Double Corona Treatment
Frequently Asked Questions
About Samples
  • Testing samples are available free of charge
  • Freight for sample delivery is the responsibility of the receiver
  • Freight costs will be refunded by deducting from subsequent orders
  • Prepaid shipping is recommended for cost efficiency
About Capacity
  • 5 coating production lines
  • 20-day delivery for a 40-foot container
  • 850 tons monthly production capacity
About Responsibility and After-sale Service
  • 12-month warranty period
  • Equivalent compensation provided for any quality issues
Contact Us for Updated Pricing and Free Samples
WhatsApp: +8618950122853
Email: calibur.wei@after-printing.com

Send us an inquiry to receive current gloss laminating film pricing and free testing samples.
