Specifications
Brand Name :
Firepower
Model Number :
MG3-1C
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,T/T
Supply Ability :
500pcs
Delivery Time :
1 week
Packaging Details :
Carton Box
Measuring range :
±400°/s
Zero-bias instability :
0.1°/h
Random walk :
0.05°/√h
Zero-bias repeatability :
1°/h
Bandwidth :
250Hz
Steady-state power consumption :
＜1.4W
Description

Product Descripion

Micro Gyroscope Assembly is a compact sensing unit designed to measure two- or three-axis angular rates of a carrier. It integrates a high-performance MEMS gyroscope, temperature sensor, signal processing board, and embedded software.

The system provides accurate angular rate data through RS-422 output, featuring built-in error compensation for temperature drift, installation misalignment, and nonlinearity, ensuring high precision and stability.

With its small size, low power consumption, and high reliability, it is ideal for inertial navigation, attitude control, UAVs, robotics, and stabilization systems.


technical parameters

1.2.1 Technical index of gyroscope

Parameter

Unit

Test conditions

MG3-1A

MG3-1C

MG3-1E

Measuring range

°/s

±400

±400

±300

Zero-bias instability

°/h

Allan variance

0.3

0.1

0.2

Zero bias stability

°/h

10s smooth, RMS, Room temperature

3

1

1

Zero bias variation at full temperature

°/h

10s smoothing, RMS, temperature change rate

1℃/min

20

10

5

Random walk

°/√h

Allan variance

0.15

0.05

0.03

Output noise

p-p

Peak (Half Peak, RMS * 3)

0.3

0.25

0.2

Zero-bias repeatability

°/h

Q = 6, Room temperature

3

1

0.5

Zero bias acceleration sensitivity

Test at ± 1 g

2

2

2

Resolution

°/h

2

1

1

Bandwidth

Hz

250

250

400

Scale factor nonlinearity

ppm

Room temperature

100

Scale factor repeatability

ppm

Q = 3, Room temperature

100

Cross coupling

%

Room temperature

0.1

1.2.2 Electrical characteristics

Parameter

Unit

MG3-1A

Voltage

V

+5±0.25

Startup current

mA

＜400

Steady-state power consumption

W

＜1.4

Ripple

mV

100

1.2.3 Environmental adaptability

Parameter

Unit

MG3-1A

Operating temperature

℃

-45~85

Storage temperature

℃

-55~105

1.2.4 Others

Parameter

Unit

MG3-1A

Weight

g

52±5

Start time

s

1
