10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
10-Axis Inertial Navigation Sensor IMU with 3-Axis Accelerometer Gyro Magnetometer Barometer
Specifications
Brand Name :
FIREPOWER
Model Number :
16488HB
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C,T/T
Supply Ability :
500/month
Delivery Time :
1 week for sample
Packaging Details :
sponge +carton
Gyroscope range :
500/ 2000°/s
Zero bias stability :
0.8°/h
Scale factor accuracy, Z-axis :
0.3%
Angular random walk :
0.15 °/ √hr
Noise density :
0.001°/s/ √Hz
Bandwidth :
200Hz
Description

All-in-One Inertial Measurement Unit
The 16488C IMU is an all-in-one inertial measurement unit equipped with a 3-axis gyroscope, accelerometer, magnetometer, and barometer. It compensates for various errors such as temperature variations, misalignment, and nonlinearities, ensuring high accuracy and reliable data output via SPI or UART communication for critical system integration.


Main technical parameters

Table 1-1 Technical Parameters

Parameter

Test conditions

Minimum value

Typical value

Maximum value

Unit

Gyroscope

Dynamic measuring range

Configurable

±450

º/s

Zero-bias instability

Allan variance, better than

5

º/h

Zero bias stability

10s smooth, RMS, better than

10

º/h

Zero bias in full temperature range

-40 ℃ ~ 85 ℃, 10 s smooth,

rms

60

º/h

Random walk

1σ

0.26

º/√h

Zero-bias repeatability

1σ

20

º/h

Zero-bias acceleration sensitive

20

º/h/g

Scale factor repeatability

1σ

200

Ppm

Scale factor nonlinearity

FS=450 º/s

200

Ppm

Bandwidth (-3dB)

330

Hz

Cross coupling

0.2

%

Accelerometer

Dynamic measuring range

Configurable

±20

g

Zero bias stability

Allan variance

0.07

mg

Zero bias in full temperature range

-40 ℃ ~ 85 ℃, 10 s smooth,

rms

3

mg

Random walk

1б

0.029

m/s/√h

Zero-bias repeatability

1б

0.5

mg

Zero bias stability

10s smooth, RMS, better than

0.25

mg

Scale factor repeatability

1σ

500

ppm

Scale factor nonlinearity

FS=10g

500

ppm

Bandwidth (-3dB)

250

Hz

Cross coupling

0.2

%

Magnetometer

Dynamic measuring range

±2.5

gauss

Sensitivity

0.1

mgauss/LSB

Barometer

Pressure range

300

1100

mbar

Sensitivity

6.1 × 10-7

mbar/LSB

Electrical

Characteristic

Voltage

Direct current

3.3±0.15

V

Power consumption

0.5

W

Ripple

P-P

100

mV

Weight

48±2

g

Use

Environment

Operating temperature

Scalable

-45

85

℃

Storage temperature

-55

85

℃


Outline Drawing
