Specifications
Brand Name :
Firepower
Model Number :
MG3-1A
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200/MONTH
Delivery Time :
30 DAYS
Packaging Details :
Sponge+ box
Measuring Range :
400°/s
Random Walk Cefficient :
≤0.15°/√h
Zero Bias Stability :
≤0.3°/h
Interface :
RS-232 or RS-422
Scale Factor Nonlinearity :
<100ppm
Scale factor repeatability :
<100ppm
Description

MG3-1A MEMS Gyroscope is a high-accuracy 3-axis angular rate sensor for autonomous vehicles, UAV navigation, and robotics applications.
Featuring MEMS gyroscope technology, temperature sensors, signal processing board, structural framework, and software, it outputs fully compensated angular rate data via RS-422, including temperature, alignment, and nonlinearity correction.
Specifications: ±400°/s range, zero-bias instability 0.3°/h, random walk 0.15°/√h, bandwidth 250 Hz, start-up 17 s, weight 52 g. Ideal for UAV gyroscopes, robotic stabilization, mapping instruments, and autonomous navigation systems.
Fully compatible with Stim210, it provides a compact, reliable drop-in MEMS gyroscope solution.


Main technical parameters

1.2.1 Technical index of gyroscope

Parameter

Unit

Test conditions

MG3-1A

MG3-1C

MG3-1E

Measuring range

°/s

±400

±400

±300

Zero-bias instability

°/h

Allan variance

0.3

0.1

0.2

Zero bias stability

°/h

10s smooth, RMS, Room temperature

3

1

1

Zero bias variation at full temperature

°/h

10s smoothing, RMS, temperature change rate

1℃/min

20

10

5

Random walk

°/√h

Allan variance

0.15

0.05

0.03

Output noise

p-p

Peak (Half Peak, RMS * 3)

0.3

0.25

0.2

Zero-bias repeatability

°/h

Q = 6, Room temperature

3

1

0.5

Zero bias acceleration sensitivity

Test at ± 1 g

2

2

2

Resolution

°/h

2

1

1

Bandwidth

Hz

250

250

400

Scale factor nonlinearity

ppm

Room temperature

100

Scale factor repeatability

ppm

Q = 3, Room temperature

100

Cross coupling

%

Room temperature

0.1

1.2.2 Electrical characteristics

Parameter

Unit

MG3-1A

Voltage

V

+5±0.25

Startup current

mA

＜400

Steady-state power consumption

W

＜1.4

Ripple

mV

100

1.2.3 Environmental adaptability

Parameter

Unit

MG3-1A

Operating temperature

℃

-45~85

Storage temperature

℃

-55~105

1.2.4 Others

Parameter

Unit

MG3-1A

Weight

g

52±5

Start time

s

1

Overall dimension
