Specifications
Brand Name :
Ziitek
Model Number :
TIF030-05
Certification :
RoHS
Place of Origin :
Vietnam
MOQ :
1000tube
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
1000000 tube/month
Delivery Time :
3-5 work days
Packaging Details :
300cc/tube
Products name :
Thermal Conductive Gel Thermal Conductive Silicon Filler Liquid Heat Conducting Gel With Good Price
Materail :
Ceramic Filled Silicon Material
Color :
Blue
Density :
3.25g/cm³
Thermal conductivity :
3.0W/mK
Recommended Operating Temp :
-45~200℃
Keywords :
Thermal conductive gel
Description

TIF030-05 Thermal Conductive Gel Thermal Conductive Silicon Filler Liquid Heat Conducting Gel With Good Price

TIF®030-05 is a soft silicone gel-based gap filer pad, formulated with a special blend of filers to provide both excellent thermal conductivity and superior softness. Compared to conventional thermal greases, TIF®030-05 has a higher viscosity, which effectively prevents filler separation from the silicone matrix and reduces filler migration, helping maintain consistent thermal performance. It is applied in a similar manner to thermal grease and is suitable for commercial dispensing or automated equipment. Typical applications include flip-chip microprocessors, PPGAs, micro BGA packages, BGA packages, DSP chips, circular Isilicon chips, LED lighting, and other high-power electronic components.

TIF030-05 Thermal Conductive Gel Thermal Conductive Silicon Filler Liquid Heat Conducting Gel With Good Price

Feature
> Thermal conductivity: 3.0W/mK

> Soft, very low compression

> Low thermal inpedance

> Operate automaticly
> Proven long-term reliability

Application
> Mass storage devices
> Automotive electronics
> Heat-sink & frame
> LED backlight module - LED lighting

> High speed hardware driver
> Micro heat pipe

> vihicel enginee controler

> Telecom industry

> Semiconductor automatic laboratory equipment.

TIF®030-05​ Typical Properties
Property Value Test method
Color Blue Visual
Construction & Composition Ceramic filled silicon material -
Flow Rate(g/min) 30 Ziitek Test Method (30 cc syringe/ 2.5 mm orifice/ 90 psi)
Density(g/cc) 3.25g/c ASTM D297
Thermal conductivity 3.0W/mK ASTM D5470
Thermal Impedance @10psi (℃.in²w) 0.08 ASTM D5470
Thermal Impedance @50psi (℃.in²w) 0.075 ASTM D5470
Recommended Operating Temp -45 ~200°C Ziitek Test Method
Dielectric Strength(V/mm) ≥4000 ASTM D149
Bond Line Thickness(mm) 0.1 Ziitek Test Mothod
Flame Rating V-0 UL 94
Shelf Life 12 months -

Product Specification:


30 cc/pcs, 98 pcs/box; 300 cc/pcs, 6 pcs/box.
Custom packaging available for automation use. Please contact us for confirming.
If you want to know our thermal products, please visit our website.

TIF030-05 Thermal Conductive Gel Thermal Conductive Silicon Filler Liquid Heat Conducting Gel With Good Price

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.
