The ZRJ-1300 automatic rewinding machine is specially developed for the rewinding of kraft paper, paper tape, and various self-adhesive materials, delivering stable and efficient performance for flexible material processing.
Product Features
Equipped with an HCFA motion control system, featuring servo-driven control for core processes including winding, active traction, label turnover, label pulling, unloading, winding press roller, cutter assembly, waste collection, and paper tube handling.
Adopts a high-precision indexer transmission positioning structure, supported by 4-axis automatic shaft changeover to realize non-stop production and significantly enhance overall processing efficiency.
Equipped with automatic smoothing bars at both winding and finishing stations, ensuring tight, wrinkle-free sealing and rapid end finishing.
Servo-controlled press roller displacement ensures consistent and optimal clearance between the press roller and material roll, achieving smooth and even rewinding.
Supports dual rewinding modes: rubber-side winding and base paper peeling & material collecting, adapting to diverse process requirements.
Fully automated workflow integration: paper tube loading, servo tube threading, automatic labeling, precision cutting, end finishing, and automatic product discharge.
Automatic tension release with closed-loop tension stability control ensures flat lamination and reliable, steady operation during startup and shutdown.
Servo motor traction enables accurate length counting, while torque winding maintains consistent and precise tension control throughout production.
Flexible operating modes: adhesive-side rewinding or base paper stripping rewinding to meet different application scenarios.
Inflatable shaft unwinding with pneumatic lifting, automatic deviation rectification, and magnetic powder brake for precise torque and unwinding control.
Fitted with tungsten steel circular cutter for long service life, clean cutting edges, and consistent cutting quality.
Complete intelligent alarm system for real-time monitoring of material shortage, cut-off faults, and missing paper tubes.
Intuitive HCFA motion control platform with one-key startup and simplified parameter setting for quick specification switching.
