Power Electronics Grade Closed Type Water Cooling System With 10–90KW Heat Dissipation
Power Electronics Grade Closed Type Water Cooling System With 10–90KW Heat Dissipation
Specifications
Brand Name :
YUDA
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
30days
Packaging Details :
Wooden Case
Powerrating :
10W - 10kW
Coolingmethod :
Air cooling / Liquid cooling
Applications :
Renewable energy, Motor drives, Power supplies
Protectionfeatures :
Overvoltage, Overcurrent, Thermal shutdown
Inputvoltagerange :
100V - 600V
Type :
Electronic Device
Function :
Control and conversion of electrical power
Productname :
Power Electronics
Efficiency :
85% - 98%
Operatingtemperaturerange :
-40°C to 85°C
Description
Power Electronics Grade Closed-Type Water Cooling System With 10–90KW Heat Dissipation And 10–170 L/Min Flow For Industrial Thermal Management
Designed specifically for electrical power control systems this advanced closed-type water cooling system integrates a filter, expansion tank, and plate heat exchanger to provide stable and efficient cooling for high thermal load industrial equipment. Its fully closed-loop design ensures precise temperature control, minimizes contamination risks, and supports continuous operation, delivering long-term performance and operational safety for critical inverters, converters, energy storage modules, and other electrical power control systems infrastructure.
Technical Specifications
Heat dissipation power range 10-90 kW
Cooling medium flow range 10-170 L/min
Temperature difference range ≥5℃ between inlet temperature of cooled device and inlet water temperature
Cooling medium Deionized water (external cooling: industrial circulating water)
System static pressure 0.15 MPa
Design pressure 1.0 MPa
Test pressure 1.0 MPa
PH external water coolant 6-9
  • Frame-cabinet design with strategically placed exhaust and drain valves for easy maintenance
  • Comprehensive system includes main circulating pump, electric three-way valve, filter, expansion tank, plate heat exchanger, and control system
  • Advanced temperature and pressure monitoring with both independent operation and remote control capabilities via terminal or serial port communication
  • Engineered for stability across various working conditions with optimized heat dissipation
  • Constructed with stainless steel and purple copper components for compatibility with deionized water cooling medium
Key Features
  • Engineered for power conversion technology applications with high thermal density and continuous operation
  • Fully closed-loop water circulation with integrated filter, expansion tank, and plate heat exchanger ensures safe, contamination-free operation
  • Flexible cooling medium flow of 10-170 L/min provides adaptable thermal management for diversepower conversion technology systems
  • Maintains a minimum temperature difference of ≥5°C for stable and efficient cooling under high load conditions
  • Modular and compact design allows seamless integration into industrial equipment, energy storage systems, and automation lines
Global Market Applications
With its reliable performance and flexible design, the Power Conversion Grade Closed-Type Water Cooling Systemis suitable for deployment in industrial facilities worldwide. It supports efficient thermal management for power conversion technology equipment in factories, renewable energy plants, energy storage systems, and automation projects. Trusted by system integrators and manufacturers, this cooling system ensures stable operation, reduces maintenance requirements, and delivers long-term performance for power conversion technology applications in the global market.
