Specifications
Model Number :
TP-72
Brand Name :
ymiho
Place of Origin :
Wuxi, China
MOQ :
100
Price :
$5.39-8.30 / piece
Accuracy Class :
2.5
Display Type :
Analog Only
Supply Voltage :
220/110V
Dimensions :
72x72mm
Operating Temperature :
-20~+50
Measuring Range :
60~180A
Case Material :
ABS
Base Material :
PPO
HS Code :
9030339000
Outer Carton Size :
41x35x35cm
QTY/CTN :
100pcs/CTN
G.W. :
17KG
N.W. :
15KG
Packaging Details :
carton packaging
Delivery Time :
15 work days
Description
KLY-2F96 Analog Double Pointer-type Frequency Meter
Panel-mounted analog frequency meter designed for AC current measurement at 50-60 Hz with dual pointer display.
Product Construction
Square Type series features durable construction with non-combustible ABS plastic external cases and PPO plastic bases. Alternatively, non-combustible PC plastic material can be used for both case and base. Both materials maintain structural integrity without deformation during long-term use at 70°C and 120°C respectively.
OEM services available including custom ranges, changeable scales, waterproofing, and other modifications.
Technical Specifications - Ammeters
Type AC Ranges DC Ranges
mA 100mA, 150mA, 200mA, 400mA, 500mA 100mA, 150mA, 200mA, 400mA, 500mA
A 1A, 1.5A, 3A, 5A, 7.5A, 10A, 15A, 20A, 25A, 30A, 40A, 50A, 60A, 75A, 100A 1A, 1.5A, 3A, 5A, 7.5A, 10A, 15A, 20A, 25A, 30A, 40A, 50A, 60A, 75A, 100A
With External CT (ACA) X1A: 10/1A, 15/1A, 20/1A, 30/1A, 40/1A, 50/1A, 60/1A, 75/1A, 100/1A, 150/1A, 200/1A, 300/1A, 400/1A, 500/1A, 600/1A, 1000/1A
X5A: 10/5A, 15/5A, 20/5A, 30/5A, 40/5A, 50/5A, 60/5A, 75/5A, 100/5A, 150/5A, 200/5A, 300/5A, 400/5A, 500/5A, 600/5A, 1000/5A		 With External Shunt (DCA): 50mV, 60mV, 75mV
Ranges: 10A, 15A, 20A, 30A, 40A, 50A, 60A, 100A, 150A, 200A, 250A, 300A, 400A, 500A, 600A, 800A, 1000A, 1500A, 2000A, 2500A, 3000A
Additional ranges can be customized according to requirements.
Technical Specifications - Voltmeters
AC Voltage Ranges DC Voltage Ranges
10V, 30V, 50V, 75V, 100V, 120V, 150V, 200V, 250V, 400V, 450V, 500V, 600V 10V, 30V, 50V, 75V, 100V, 120V, 150V, 200V, 250V, 400V, 450V, 500V, 600V
Product Images
Analog Double Pointer Type Frequency Meter For AC Current 50-60Hz Analog Ampere Meter Analog Double Pointer Type Frequency Meter For AC Current 50-60Hz Analog Ampere Meter Analog Double Pointer Type Frequency Meter For AC Current 50-60Hz Analog Ampere Meter Analog Double Pointer Type Frequency Meter For AC Current 50-60Hz Analog Ampere Meter
Dimensions (millimeters)
Model Case Dimension A Case Dimension B Dimension C Dimension D Panel Cutout E Panel Cutout F
TP-96 96.5 96.5 69.4 64 91 91
TP-72 71.8 71.8 69.4 64 67.5 67.5
TP-48 48.3 48.3 69.4 64 44.2 44.2
