Specifications
Brand Name :
YINGER HOIST
Model Number :
PA
Certification :
CE GS ISO
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
Western Union, T/T, L/C, D/A, D/P, MoneyGram
Supply Ability :
1000units per week
Delivery Time :
5-8work days
Packaging Details :
wooden cases,on pallets,and we can also make the packing according to buyers request.
Price :
Negotiable
Lifting Weight :
100-1200KG
Lifting Height :
6m12m
Sling Type :
Wire rope
Lift Speed :
10m/min
product name :
Electric Wire Rope Hoist
Weight :
23kg
Description

220v single phase 1500kg 2000kg Electric Hoist Wire Rope Electric Hoist Portable Hoist Mini Electric Hoist with trolley

220v Mini Size Electric Wire Rope Hoist With Trolley Long Life Time electric wire rope hoist with motorized trolley

1)The emergency stop switch
2)Upper limit function
3)Thermal protection terminal
4)Protection class:IP54
5)Insulation class:B
6)Group of mechanisms:M1
7)Work Duty: S3-25%-10min
8)Rated Volt: 220/230V ~ 50Hz
9)Rated Current: 2.0A
10)Input Power: 1600W
11)Lifting Weight: 500kg (Single-line), 1000kg (Double-line)
12) Lifting Height: 12m (Single-line), 6m (Double-line)
13)Lifting Speed: 10m/min (Single-line), 5 m/min (Double-line)
14)Diameter of wire rope: 3.0mm
15)Tensile strength of wire rope ≥ 1870N/mm2

Model PA200 PA250 PA400 PA500 PA600 PA800 PA1000
Rated Volt(V) 230-50hz S3 20% 10 min
Input Power (w) 450 500 750 900 1050 1300 1600
Rate Lifting(kg) 100/200 125/250 200/400 250/500 300/600 400/800 500/1000
Lifting height(m) 12/6
Lifting speed(m/min) 10/5
Packing dimensions(cm) 44*38*20 44*37*25 44*37*25 44*37*25 53*45*19 53*28*35 53*28*35
G.W/N.W 24/22 25/24 25/33 36/34 41/38 38/36 40/38
Quan/ctn(pcs) 2 2 2 2 2 1 1
