MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER
Specifications
type :
Other Type
Interface :
usb
Host Interface: :
USB 2.0 CCID (USB 1.1/3.0 compliant)
USB Connector: :
USB Type A
Smart Card Interface Speed :
Up to 600 kbps (depending on card)
Card Size: :
ID-1
Driver: :
PC/SC Driver
Support Systems: :
Win2000+/Linux/MacOS/Android
Description
Product Description

MCR3521 Contact Smart Card Reader

MCR3521 USB Contact Smart Card Reader ISO7816 - ID CARD READER

• READY TO USE
Driver support for all major PC operating systems
• SUPPORTS ALL APPLICATIONS
Supports all major smart card ICs and technologies in just one device
• FAST
Transaction time optimized for maximum end-user acceptance
• CONVENIENT
Ultra-compact and robust design streamlined for mobile operation
MCR3521 is a contact smart card reader, Compared with other smart card readers on the market, it has two main features: One is that we have specially added a counterweight for it. The product weighs 405g, which is more suitable for one-handed operation on the desktop and is more convenient; the other Is the reader adopts a landing IC card socket;
Specification
PARAMETER
MCR3521
Host Interface
USB 2.0 full speed (12 Mbps)
Smart Card Interface
Supported Standards
ISO/IEC 7816 Part 1 to 4
Supported Tag ICs
All major ISO/IEC 7816 compliant Smart Card IC support
Smart Card Protocols
T=0, T=1，synchronous cards I2C and 3-wire
Smart Card Interface Speed
• Up to 600 kbps (depending on card)
• TA1=97
Smart Card Clock Frequency
ISO/IEC 7816 compliant; Operates up to 16 MHz
Supported Smart Card Types
5V, 3V and 1.8V, ISO/IEC 7816 Class A/B/C
Power to Smart Card
60mA in Class A; 55mA in Class B; 35mA in Class C
Smart Card Detection
• Card present switch
• Automatic power on/off
• Short circuit protection
Card Size
ID-1
Contact Type
Landing Contact Socket (8 pin)
Driver and Software
PC/SC Driver
PC/SC Specification Ver. 2.0
• Windows® XP/Vista/7/8/10 (32/64 bit), Windows® Server 2003/2008/2012, Windows® CE 6.0, 7.0
• MacOS 10.5.x, 10.6.x, 10.7.x, 10.8.x, 10.9.x, 10.10.x, 10.11.x
• Linux 2.4.x, 2.6.x (32/64 bit)
Software
• PC/SC API
• CT-API (through wrapper on top of PC/SC)
• Synchronous-API (through wrapper on top of PC/SC)
• M-Card API (through wrapper on top of PC/SC)
Operating Conditions
Power Supply

Bus-powered USB
Power Consumption

< 20 mA with standard smart, < 500 μA in Standby Mode
Dimensions

95x 65 x 98mm
Weight

405 g ± 5% / 0.15 lb ± 5%
Operating Temperature Range

0° to 50° C (32° to 122° F)
Storage Temperature Range

-20° to 60°C (-4° to 140° F)
Operating Humidity Range

Up to 95% RH non-condensing
Durability
Landing contact 50,000 card insertions
Connector

1.5m long with USB type A connector
Status Indicator

Green LED
Firmware

SmartOS™
Firmware In-Field Upgradeable
No
Company Profile
Markland(MTTEK) was established in 2009, headquartered in Hong Kong, and has branches in Shenzhen and Beijing. We are an innovative smart card solution provider, focusing on the fields of physical security and information security, and providing customers with high-end solutions and service.
We provide solutions from hardware to software: - Solutions: e-ID/passport solutions, e-payment solutions, NFC solutions, Bluetooth read-write solutions, SIM card read-write solutions，Biometric Solutions; - Hardware: Contact smart card readers and modules that follow the ISO/IEC 7816 protocol standard, Contactless smart card readers and modules based on 13.56MHz, E-passport reader and module that comply with ICAO 9303 standard, And optical identification based fingerprint readers and modules； Markland is the important cooperation partner in Asia of Identiv Group which is the world’s security products manufacturer ,and we are the only agent of Identiv in mainland China.Through years of unremitting efforts, we have benefited from IDENTIV's technical support, customized and developed products and solutions that are more suitable for market needs, and cooperated with IDENTIV to customize products and solutions for its global customers.
