Specifications
Brand Name :
qipang
Model Number :
QP400
Certification :
SGS
Place of Origin :
China suzhou
MOQ :
MOQ≥1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 PC per day
Delivery Time :
12-17 working day
Packaging Details :
Carton, wooden box
Name :
small winding machine
Material :
Aluminum Alloy
Weight :
160 kg
Function :
winding rope
Application :
counter meter
Model :
QP400 take up machine
Warranty :
1year
Wire range :
1-5mm
Voltage :
220V
Description

suzhou good quality wire take up and pay off machine with counter meter

Selection parameter

Model TC300 TC 400 TC 500
Line diameter φ0.1-φ3mm φ1-φ5mm φ0.1-φ5mm
Spool size ≤φ300 ≤φ400 ≤φ500
Coiling speed 110r/min 280r/min 280r/min
Take-up motor 1*0.18KW 1*0.37KW 1*0.37KW
Cable way Bearing Traverse Bearing Traverse Bearing Traverse
Take-up strength 8N/M 10N/M 10N/M
Load bearing 20KG 30KG 30KG


Powerful Wire Spooling Equipment High Efficiency With Counter Meter

"Quality first, customer first" Shanghai Kai Pang Industrial Co., Ltd. is a high-tech enterprise integrating R&D, design, manufacture and service of wire equipment, and has its own import and export rights. The company was founded in 2003 and has passed ISO9001:2008 quality management system certification and SGS third-party authority certification. The company's main customers come to Central Europe, South America, South Africa, most of Asia. Companies adhere to the quality of survival, integrity to win the customer's operating principles, down-to-earth to actively listen to the valuable opinions of users.

Product display​
Powerful Wire Spooling Equipment High Efficiency With Counter Meter
Powerful Wire Spooling Equipment High Efficiency With Counter Meter

Powerful Wire Spooling Equipment High Efficiency With Counter Meter

Powerful Wire Spooling Equipment High Efficiency With Counter Meter


1. Applicable coil PND400- 600mm

2. Release method: active release

3. Chuck mode: shaftless thimble clamping

4. Lifting method: oil pressure lifting

5. Take-up motor: 4KW

6. Inverter power, 4KW

7. Line speed: 0-300 m / min

8. Storage line guide wheel outer diameter: 250mn (aluminum alloy made up to five down four)

9. Line type: vertical type

10. Braking method: pneumatic brake

9. Link with the customer's previous device

10. Machine color: sea blue + beige orange
