The Standard Industrial 102 Curing Oven is engineered for curing oil-based paints, alkyd resins, epoxy coatings, and polyurethane finishes on wood and metal substrates. Utilizing forced hot air circulation with indirect electrical heating, this oven ensures uniform temperature distribution (±3°C across the chamber) for consistent drying and cross-linking of solvent-based coatings.

• Loading Conveyor Platform - manual or automated roller infeed
• Main Curing Chamber - thermally insulated, 1,200×1,200×1,800 mm (customizable dimensions)
• Heating System - electrical resistance or hot air circulation
• Temperature Control Unit - PID controller with digital display
• Exhaust Air System - with integrated damper for solvent vapor extraction
• Safety Interlock Latch - automatic power cut when door opened during operation
• PLC Control Cabinet - industrial-grade controller with 7-inch touchscreen HMI
• Data Recording Interface - USB/Ethernet port for curing parameter logging

• Wooden furniture and cabinetry - curing oil-based primers and topcoats
• Metal parts and machinery - industrial equipment coating curing
• Automotive components - chassis parts, engine covers
• Architectural products - doors, window frames, railings
• Industrial painting service shops - small to medium batch production

• Customizable chamber size - from 600×600×600 mm (lab) to 2,500×2,500×3,000 mm (industrial pallet)
• Customizable temperature range - up to 350°C for specialized coatings
• Customizable heating power - match chamber size and throughput requirements
• Customizable airflow pattern - vertical downflow, horizontal crossflow, or bottom-up
• Customizable voltage and frequency - for any global location
• Customizable door configuration - single-door, double-door, or roll-up
• Customizable safety package - ATEX certification for solvent-based coatings

• Uniform heat distribution - forced air circulation eliminates cold spots
• Precise PID control - ±1°C accuracy for consistent curing across batches
• Multi-stage curing profiles - store up to 50 recipes; typical example: 60°C solvent flash-off → 120°C cross-linking
• Safe for solvent-based coatings - explosion-proof heating elements + purge cycle
• Energy efficient - high-density rock wool insulation (100-120 mm) reduces heat loss
• Quick load/unload - optional motorized loading cart available
• Data traceability - USB/Ethernet export of curing parameters for quality records

• Lifetime free technical support (phone/email/video)
• On-site installation & commissioning - engineers available worldwide
• Operator training - 2-3 days on-site training included
• 2-year warranty - on heating elements, PLC, fans, and all electronic components
• Spare parts supply - guaranteed for 10+ years; 48-hour global shipping
• Free sample testing - send your coated products; we provide curing test report

• Packed in export-grade plywood case with VCI anti-rust film and foam padding
• Shipped assembled or in modular sections for container loading
• Includes: English manual, CE certificate, wiring diagrams, calibration certificate, tool kit, spare parts
• Lead time: 20 days (standard); 35-50 days (customized)
