Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Certification :
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
MOQ :
1
Price :
15000-35000 per unit
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Model NO. :
CLW6688YSLJCA32
Volume :
6001-10000L
Emission Standard :
Euro 3
Transmission Type :
Manual
Payload :
4tons, 5tons
Fuel :
Diesel
Drive Wheel :
4×2
Brand :
JAC
Models :
Small
Usage :
Dump, Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
Condition :
New
Chassis Brand :
Dongfeng, Foton, Sinotruk, JAC, etc.
Compression Ratio :
0.72~0.8 Ton/M3
Logo :
as Per Customer's Request
Garbage Box Thickness :
Side 4mm, Bottom 4mm, Carbon Steel
Hydraulic Systemtime :
One in Cab, One on The Back of The Truck
Hopper Volume :
0.8cbm
Dirty Water Tank Volume :
0.2cbm
Loading Capacity :
4tons, 5tons, 6tons
User Manual :
Yes
Operating Video :
Yes
Horsepower :
125HP or 140HP
Wheelbase :
3360mm, 3815mm
Cabin :
2/3 Persons with A/C
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Specification :
6tons, 8cbm
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909090
Production Capacity :
500 Unit/Month
Name :
Garbage Truck
Description
Refuse Compressor Truck JAC Waste Collector Compressed 4tons 6tons Compactor Garbage Truck
Description:
  • Garbage Refuse Compactor truck is divided into compactor garbage truck, swing arm garbage truck, hook lift garbage truck, roll on roll off garbage truck,bin lift garbage truck,dumper garbage truck,sealed garbage truck,container garbage truck, rear load garbage truck and so on.
  • Easy Full Automatic Operation: computer control system for loading and unloading operations.
  • One Person Operation: Reducing sanitation working, greatly improves the working environment.
  • Double Operation System: computer control system and manual operation greatly improves the vehicle usage rate.
  • Capacity of Garbage Refuse Compactor truck : option for 3-20m3 garbage truck.
  • Steering wheel of Garbage Refuse Compactor truck : both left and right hand drive,meet the needs of different countries
  • Emission standard of Garbage Refuse Compactor truck : option Euro 1,Euro 2,Euro 3,Euro 4,Euro 5 garbage truck
  • Truck chassis of Garbage Refuse Compactor truck : option for japanese and chinese brand,such as dongfeng,,faw,foton,howo,jac,jmc,forland...
Specifications Detail of the Truck :
JAC 6cbm or 8cbm Garbage Refuse Compactor truck
Overall Dimension 7400×2250×2750 mm Gross Vehicle Weight 8280 kg
Curb Weight 6430 kg Loading Weight 1655 kg
Wheel Base 3360 or 3800 mm Front / Rear Axle 2500 kg / 6000kg
Cabin Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio,
Engine horsepower 140HP, EURO III
Max Driving Speed 90 km/h
Gear Box 5 Forward Gear, 1 Reverse Gear,
Tire 7.00R16 (6 pieces with one spare)


Garbage Bin

 Capacity 8CBM
Material 4mm Carbon Steel for Garbage Bin Body
Design Whole unit with Leakage Proof Design
Ways of Loading Rear Loading with optional Bucket Lifting System
Garbage Compact Ratio 1/3 - 1/4
Control System One control Panel on the back, One Control system in back of Cabin




Dispensing System

 1. Equipped with air-tight dustbin, hydraulic system and operating system.
2. Automatic loading, compressing and discharging, all handled by 1 person
3. Sewage water collection tank to avoid any pollution during handling.
4. Large Pressure, Good Leakage Proof, Convenient Operation
Dependable Security
5. Electrical Control Panel for compacting system.
6. Cycling time<14~18s
Remarks 1. Color is optional
2. Customized LOGO painting as per customer request.
