Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Name :
Garbage Truck
Certification :
ISO9000, CCC, TS16949, CE
MOQ :
1
Price :
15000-35000 per unit
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Model NO. :
CLW5312GYQ124
Volume :
＞15000L
Emission Standard :
Euro 3
Transmission Type :
Manual
Payload :
12 Tons
Fuel :
Diesel
Drive Wheel :
6×4
Brand :
Dongfeng
Models :
Medium
Usage :
Dump, Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
Condition :
New
Material :
Carbon Steel
Horsepower :
240HP
Logo :
as Per Customer's Request
Loading Capacity :
10tons 12tons 10t 12t 10ton 12ton
Driving Type :
LHD,Rhd
Loading Method :
Rear Loading,Back Loading
Chassis Brand :
Dongfeng,Foton,HOWO,Shacman
Body Thickness :
Side 4mm Bottom 5mm
Campacting Ratio :
0.6-0.8 Ton/Cbm
Engine :
Diesel Engine Cum-mins
After Sales Service :
Overseas Technical Support
Tire :
10r22.5 Tubeless Tire,10 PCS with One Spare
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Specification :
12tons, 12t, 12ton, 16cbm, 16000liters
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909090
Production Capacity :
500 Unit/Month
Description
12tons Dongfeng 10-wheel 240hp Left Right Hand Drive 16cbm Garbage Compactor Truck
Product Description
  • Garbage Compactor Truck is divided into compactor garbage truck, swing arm garbage truck, hook lift garbage truck, roll on roll off garbage truck,bin lift garbage truck,dumper garbage truck,sealed garbage truck,container garbage truck, rear load garbage truck and so on.
  • Easy Full Automatic Operation: computer control system for loading and unloading operations.
  • One Person Operation: Reducing sanitation working, greatly improves the working environment.
  • Double Operation System: computer control system and manual operation greatly improves the vehicle usage rate.
  • Capacity: option for 3-20m3 garbage truck.
  • Steering wheel: both left and right hand drive,meet the needs of different countries
  • Emission standard: option Euro 1,Euro 2,Euro 3,Euro 4,Euro 5 garbage truck
  • Truck chassis: option for japanese and chinese brand,such as dongfeng,faw,foton,howo,jac,jmc,forland...
  • Specifications of Garbage Compactor Truck
Drive type 6*4, New condition, LHD





Vehicle Main Dimensions

 (L x W x H)mm 10280×2500×3250
Wheel base (mm) 4350+1350
Track front/rear mm 2040/1860
F/R Axle-Load 7000/18000 kg,
Approach/departure angle 8/12
Weight in KGS Curb Weight 16300kg
GVW 25000kg
Max. driving speed(km/h) 98




Engine

 Brand Brand,Diesel ENGINE
Model B245 33 or B270 33
Type 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling;
Horse Power(HP) 245hp or 270hp
Emission standard Euro III
Gearbox 6 forwards& 1 reverse
Clutch Reinforced diaphragm clutch
Tire 11.00R20,111.00R20,12R22.5 or 12R22.5, 11 pc including 1 spare tire
Steering Gear power steering, hydraulic steering with power assistance
Equipment for Garbage Compactor
Garbage Box Material Carbon Steel Q235
Garbage Box Volume 16cbm or 18cbm
Body material Floor plate 5mm and side plate 4mm
Waste water tank 200L
Filling container volume 500L
Filling time 8~10s
Filling cycle time 50~60s/time
Discharge time 30~40s
Hydraulic System Chinese brand,consist of oil pump,oil cylinder,front valve,rear valve,pressure gauge,oil box,filter and pipelines.Front valve controls push panel and strike-off board.
Push Panel Used to push and squeeze garbage,works together with the skid way in the box
