ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
ISuzu 600p 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector Truck
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Fuel :
Diesel
Wheel Base :
3360mm,3800, 3950mm,4500mm,etc.
Emission Standard :
Euro 5
Transmission Type :
Manual
Brand :
ISuzu
Origin :
Suizhou, China
Time of Discharging :
<60s
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Models :
Small
Cycle Time of Filling :
<40s
HS Code :
8705909090
Tire :
Radial Tires
Trademark :
CLW
Specification :
6800*1960*2600mm
Usage :
Dump, Sealed, Compression Type
Condition :
New
Gearbox :
5 Forwards &1 Reverse
Delivery Time :
35 Days
Certification :
ISO9000, CCC, TS16949, CE
MOQ :
1
Price :
15000-35000 per unit
Drive Wheel :
4×2
Color :
According to Customer Requirements
Lifting Time of Filler :
8-10s
Model NO. :
CLW5073GB
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Volume :
3001-6000L
Payload :
3ton,4ton,5ton,8ton,10ton,12ton,18ton,etc
Logo :
as Per Customer's Request
Steering Gear :
Power Steering
Name :
Garbage Compactor Truck
Chassis Brand :
Dongfeng, Foton, FAW, etc.
Production Capacity :
500 Unit/Month
Storage :
Garbage
Description
600P 5m3 6m3 8m3 Garbage Compactor Truck Rear Loading Rubbish Waste Collector
Description:

1.The collection garbage truck usually called garbage compactor truck, compression garbage truck, waste compactor truck,compactor garbage truck,etc.

2.The garbage compactor truck is an ideal compactor for large clean up operations. It is simple to operate and highly effective with excellent compaction ratio. It is ideally suited to municipal applications where large amounts of mixed industrial and domestic waste is to be collected.

3.Our garbage compactor truck for sale is consisted of four main parts, sealed garbage compartment, hydraulic system, operating system and lifting cylinder.fully sealed It can compact and dump the garbage automatically. Sewage will flow in the compartment completely to avoid re-pollute during transportation.

As a professional special vehicle manufacturer in China, the garbage compression truck we produce is from 4cbm to 25cbm.

Cabin

 Driving type 4x2
with A/C. Left Hand Drive.

Vehicle Main Dimensions

 Overall dimensions (L x W x H)mm 6800x1960x2600
Wheel base (mm) 3360
Wheel track (front/rear) (mm) 1504/1425
Approach/Departure angle(°) 24/16

Weight in KGS

 Tare Weight 5050
Front axles loading capacity 2580
Rear axles loading capacity 4720
Max. driving speed(km/h) 110

Engine

 Brand I SUZU
Model 4KH1-TCG51
Type 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 120 HP
Emission standard Euro V
Gearbox 5 forwards &1 reverse
Clutch Diaphragm spring clutch
Steering Gear Power steering
Tire 7.00R16 All radial tires with one spare, 7 pieces
Compression garbage box body system
BodyVolume 5m3
Cycle Time of Filling(S) ≤40
Lifting Time of Filler(S) 8-10
Time of Discharging ≤60
Working Pressure(MPA) 16
Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compress and dump the garbage .and the sewage generated in the process of the compression all go into the sewage tank.
