Heavy Garbage Refuse Compactor Truck HOWO 6x4 Refuse Compressor Truck 15m3 20m3

Specifications

Chassis brand :

SINOTRUK

Wheel base :

4600mm

Maximum speed :

90km/h

Model Number :

CLW

Payment Terms :

50% Deposit,Balance should be paid before ship out

Supply Ability :

10unit per month

Engine model/HP :

WD615.62/ 266hp

System of loading :

Mechanized, rear loading

Engine Emission :

Euro 2

Tire :

12R22.5

Curb Weight :

9600kg

Condition :

New, New

Place of Origin :

CHINA

Brand Name :

CLW

MOQ :

Price :

15000-35000 per unit

Dimensions (L x W x H) (mm) :

8660X2480X3250mm

Warranty :

One Year

Name :

Garbage Truck

Transmission Type :

Manual

Emission Standard :

Euro 2

Fuel Type :

Diesel

After-sales Service Provided :

Video Technical Support, Online support, Free Spare Parts

Gross Vehicle Weight :

9600

Description

Heavy Garbage Refuse Compactor Truck HOWO 6x4 Refuse Compressor Truck 15m3 20m3

FEATURES AT A GLANCE

SINOTRUK HOWO 4X2

SHORT DELIVERY TIME

ONE YEAR WARRANTY

FACTORY DIRECTLY SELLING

Right elevation

Left elevation

Rear elevation

PRODUCT SPECIFICATIONS

Vehicle Parameters
Vehicle model	CLW5160ZYS	Vehicle brand	CLW
Vehicle dimension	8660X2480X3250mm	Curb weight	9600kg
Loading Capacity	10m3 12m3
Chassis Parameters
Chassis model	ZZ1167M4611W	Chassis brand	SINOTRUK
Overall dimensions	7990x2496x2958mm	Wheel base	4600mm
Cab	HW76 a row and a half deluxe cab(with sleeping berth), allowable 3 passengers
Engine	WD615.62
	Horse power	266hp
	Emission	Euro 2
	Displacement	9726ml
Tire	12R22.5	Transmission	10 speed forward 2 reverse
Steering device	Power assisted steering	Steering wheel	Left hand drive
Remark: Other types of chassis as optional		FOTON, Howo, Shacman, JAC
Standard Configuration
Body, sub frame, lifting rear part, the loading device, the pushing-out plate, hydraulic and electric systems


Working pressure	18MPa	Flow rate	63mL/r+20mL/r
Lifting cylinder	Φ90 x2	Scraper cylinder	Φ100 x2
Slide plate cylinder	Φ110 x2	Push plate cylinder	Φ150 x2
Tilt device cylinder	Φ63 x1
Body
Version	All-metal
Shape	arc-shaped
Sidewalls	T420 steel (thickness: 4 mm)
Bottom	Q355 steel (thickness: 4 mm)
Roof	Q355 steel (thickness: 4 mm)
Front frame	Q355 steel (thickness: 5 mm)
Rear frame	Q355 steel (thickness:5 mm)
Basis	120х120mm (thickness: 5 mm)
Loading bunker
Loading bunker	All-metal with sidewalls and a loading ladle
Volume	2 m3
Arc plate	T420 steel (thickness: 4 mm)
Slideway	T420 steel (thickness: 4 mm)
Liquid drain	Drainage channel ,sewage tank
Working zone Lighting	2 lamps
Mechanism of raising	Two hydraulic cylinders
Ensuring tightness	Between the body and lifting back part in the lower part profile acid-proof rubber is used

Working Overview

Hot sale Product

Recommend Products

Compressor Garbage Truck

Sewage Suction Truck

Refrigerator Truck

Dust Suspression Truck

Concrete Mixer Truck

Oil Tanker Truck

Fire Fight Truck

Wrecker Truck

Aerial Work Truck

Dump Truck

Swing Arm Garbage Truck

Cargo Truck

Road Sweeper Truck

Van Truck

Motor home Truck

Company Profile

Product Test and Training for Customer

We will test each product before shipment, and also provide online or face to face operation training for customer.

Design & Technical & Quality Meeting Each Week

We will discuss with R&D about the questions and feedback from customer to ensure all the quality of products and after-sales service.

FAQ

1. What is your terms of payment?

T/T with 30% deposit, and 70% balance will be paid before delivery. We will show you photos of the products and packages before you paying the balance.

2. What's your MOQ?

1 set.

3. What is your packing?

We transport our trucks by bulk cargo carrier, ro-ro or 40/45 HQ or land transportation.

4. How about delivery time?

25 workdays after we received 30% of contract value T/T down payment. customized types depends on configuration and order quantity.

5.How could you ensure the quality of products?

We have ISO certificate to control the quality system. And we will also show you the photos and videos during producing. You are welcome to visit our factory at any time.

6. Do you have advantage on price?

We offer all the trucks with factory directly selling price.

7. How about the afer-sales service?

Our engineer will be ready to offer online-supporting for any technical questions for you.
