Specifications
Brand Name :
Haitui
Model Number :
HD60
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 Unit
Price :
Negotiation
Payment Terms :
L/C, , T/T, Western Union, MoneyGram
Supply Ability :
500 Pieces/ Month
Delivery Time :
35-40DAYS
Packaging Details :
Standard packing and shipping
Engine :
QSK19-C604
Minimum Turning Radius :
6.786m
track shoe width :
610mm
track chain pitch :
280
/working pressure :
21MPa
Ripper weight :
3.59T
Description

SD60 HD60 450kw 600HP 70t Hydraulic Crawler Mining Dozer Bulldozer Construction Machinery With Ripper

Product Description

1. The main components of the whole machine adopt modular design, which is easy to disassemble and repair;


2. Cumins ECU engine,EU 3 emission,612 horsepower,air intercooler,powerful and low fuel consumption


3. The intelligent temperature control hydraulic fan dissipates heat perfectly, with reverse function to clean the radiator.


4. The K-type floating track roller suspension mechanism and lubrication track exhibit excellent ground adaptability and remarkable durability.


5. The main hydraulic components, control handles, controllers, and pipelines are supplied famous brand.


6. Quickly and efficiently control of gearing and steering with pilot.


7. The working device operate with joysticks, which is light,High control accuracy and efficiency; The 360 surround view system gives the driver a 360-degree panoramic view of the driving without any blind spots, which improves the convenience and safety of driving and riding:

the centralized lubrication system greatly improves the maintenance convenience of the vehicle and effectively guarantees the service life of the machine. Adapted from the German fuel heater, The seats are equipped with electric heating and airbag damping, which greatly improves the adaptability to extreme cold environments and driving comfort.


8. Compatible with Ripper automatic pin puller , radio, USB charging, etc.

Performance parameters:

Model HD60
Dimension(without ripper) 7641*4690*4530
Dimension(with ripper) 10390*4690*4530
Operation weight(T)(with ripper) 70.5
Operation weight(T)(without ripper) 66.85
Engine QSK19-C604
Power(kw/r/min) 450/1800
Displacement(L) 19
Max.torque(N.m/rpm) 3019/1300
Min turning radius(m) 6.835(L)/6.789(R)
Track grounding length(mm) 3842
Grounding pressure(MPa) 0.1232
Min ground clearance(mm) 610
Grade ability (°) 30
Track shoe type Single grouser
Number of track shoe 40pcs/single side
Width of track shoe(mm) 610
Track gauge(mm) 2502
Pitch(mm) 280
Number of carrier roller(single side) 2
Number of track roller(single side) 7
System pressure(MPa) 21
Blade type Semi-U blade(rocky)
BladeLxH(mm) 4692*2251
Blade capacity( m3) 18.5
Blade lift height(mm) 1661
Blade depth(mm) 716
Blade Max tilte(mm) 733(L)/731(R)
Ripper type Single shank ripper
Ripper weight(T) 3.59
Max. ripping depth(mm) 1435
Max. lifting height(mm) 1105
Product details
SD60 HD60 450kw 600HP 70t Hydraulic Crawler Mining Dozer Bulldozer Construction Machinery With Ripper
SD60 HD60 450kw 600HP 70t Hydraulic Crawler Mining Dozer Bulldozer Construction Machinery With Ripper
SD60 HD60 450kw 600HP 70t Hydraulic Crawler Mining Dozer Bulldozer Construction Machinery With Ripper
