Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission
Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission
Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission
Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission
Specifications
Brand Name :
Hincn
Model Number :
HCL615
Place of Origin :
China
MOQ :
1 set
Price :
US$1,599.00~US$3,369.00
Payment Terms :
T/T,Western Union,D/P,D/A,L/C,MoneyGram
Supply Ability :
1,699pcs/month
Delivery Time :
7~14 working days
Packaging Details :
carton package
Modulation :
TDD OFDM
RF power :
5W*2
Frequency :
566~678MHz,1420~1530MHz
Management :
Web UI and Control Uart
RF Transmission range :
Up to 150km
FHSS :
Support
Throughput :
Maximum 100Mbps
Networking mode :
Point-to-Point, Point-to-Multipoint, Relay, and Mesh
Description
Wireless HD Video Data Link for Unmanned Vehicles
Enhance your unmanned vehicle operations with our Wireless HD Video Data Link, designed for UAVs, drones, and robotic vehicles. Delivering high-definition, real-time video transmission over long distances, this system ensures low-latency, stable, and secure communication for both aerial and ground unmanned platforms.
Our solution supports plug-and-play deployment, seamless integration with existing control systems, and reliable performance in challenging environments. Ideal for industrial inspection, surveillance, mapping, and remote monitoring, it allows operators to maintain full situational awareness and precise control.
Key Features
  • High-Definition Video: HD 720p/1080p or customizable resolution
  • Low Latency & Long Range: Real-time video transmission up to 150 km
  • Secure & Reliable: AES encryption and interference-resistant technology
  • Multi-Platform Compatible: Supports UAVs, drones, and ground unmanned vehicles
  • Compact & Lightweight: Easy to mount on vehicles or drones
Upgrade your unmanned systems with a robust wireless video data link for superior control, monitoring, and operational efficiency.
Technical Specifications
Radio
Frequency566~678MHz or 1420~1530MHz (customizable)
Bandwidth3/5/10/20/40MHz
RF Power5W×2
ModulationOFDM
ConstellationBPSK; QPSK; 16QAM
DuplexTDD
ThroughputUp to 100M bps
EncryptionAES128
Power
Air Unit5W×2
Ground Unit5W×2
Size and Weight
Air Unit113.9×83.7×24.5mm / 256g
Ground Unit113.9×83.7×24.5mm / 256g
Connectivity
AntennaSMA×2
Video InterfaceEthernet×2
Other Interface2×TTL/RS232, S.bus
Environment
Working Temperature-40°C~60°C
Applications
Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission Wireless HD Video Data Link for Unmanned Vehicles – High-Definition UAV & Drone Transmission
Frequently Asked Questions
Q1. This wireless HD video data links supports IP cameras - what if I want to use a camera with HDMI or SDI video output?
The default video input is IP RJ45 Ethernet port. For cameras with HDMI, SDI, AHD, or AV output, our mini encoder device is required to encode the video and audio signals into digital data for transmission. At the receiver end, you can connect directly to computers or NVRs. For HDMI monitor output, our decoder device converts the digital data back to HDMI video and audio signals.
About Hincn Limited
Hincn Limited is a Hong Kong company specializing in HD video wireless communication solutions, founded in 2018. Our research and production center in Shenzhen was established in 2015. With 9 employees including 3 programmers and 2 engineers, we maintain long-term cooperative relationships with ADI, Xilinx, Altera, and Morningcore, serving as third-party design partners for both ADI and Morningcore.
