Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Specifications
Brand Name :
Hincn
Model Number :
HCL536-300mW
Place of Origin :
China
MOQ :
1 set (2 pcs)
Price :
US$539~US$699
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1,689sets/month
Delivery Time :
7~14 working days
Packaging Details :
carton package
Modulation :
TDD OFDM
Frequency :
806~826MHz,1428~1468MHz,1420~1530MHz
Bandwidths :
1.4/3/5/10/20MHz
Throughput :
Maximum 30Mbps@20MHz
FHSS :
Support
Networking mode :
Point-to-Point, Point-to-Multipoint, Relay
Encryption :
AES128
OEM/ODM :
Support
Description
Wireless HD Video Data Link for UAVs & Drones
The HCL536 delivers real-time HD video from your drones or UAVs with ultra-low latency. Perfect for aerial photography, FPV applications, and real-time monitoring.
Key Features
  • Long-range transmission capability
  • Secure and stable connection
  • Easy integration with drones
  • Real-time HD video transmission
Technical Specifications
Radio
Frequency 806~826MHz, 1428~1468MHz, 1420~1530MHz (customizable)
Bandwidth 1.4/3/5/10/20MHz
RF Power 300mW
Modulation OFDM
Constellation BPSK; QPSK; 16QAM
Duplex TDD
Throughput Up to 30M bps
Encryption AES128
Power
Air Unit 300mW×2
Ground Unit 300mW×2
Size and Weight
Air Unit 103.4*61.4*22mm / 142g
Ground Unit 103.4*61.4*22mm / 142g
Connectivity
Antenna SMA×2
Video Interface Ethernet×2
Other Interface 3 channels, 3*RS232, 3*TTL or 2*RS232/TTL + 1*Sbus
Environment
Working Temperature -40°C~60°C
Device Appearance
Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Application
Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission
Frequently Asked Questions
Q1. This video data link supports IP camera. What if I want HDMI or SDI video input?
The default video input is IP RJ45 Ethernet port. For cameras with HDMI, SDI, AHD or AV output, we recommend using our mini encoder device to encode the video/audio signal into digital data for transmission. At the receiver end, you can connect directly to your computer or NVR. For HDMI monitor output, our decoder device can convert the digital data back into HDMI video and audio signals.
Q2. For the 800MHz and 1.4G band, which one would be better?
If your local area has DVB-T or DVB-T2 digital television signal in the 170-860Mhz range, the 1.4G band would be better. Additionally, since GPS antennas on drones point upward and transmitter antennas point downward, the 1.4G frequency has negligible effect on GPS signals.
About Us
Hincn Limited is a Hong Kong company specializing in HD video wireless communication solutions, founded in 2018. Our research and production center is located in Shenzhen and was established in 2015. We have a total of 13 employees, including 3 programmers and 2 engineers. Our company has a long-term cooperative relationship with ADI, Xilinx, Altera and Morningcore. We are the third-party design partner for both ADI and Morningcore.
