ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
Specifications
Brand Name :
QFMH
Model Number :
BT30,BT40,BT50
Place of Origin :
CHINA
MOQ :
10PCS
Price :
USD 9/PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000PCS/MONTH
Delivery Time :
5DAYS
Packaging Details :
PLASTIC BOX
AppliCATEion :
CNC Machine
Color :
Black
Installation Method :
Screw
Length :
100mm
Material :
20CrMnTi
Packaging :
Carton
Product Name :
BT Tool Holder
Tolerance :
0.005mm
Weight :
1.2kg
model :
BT30 BT40 BT50 ER Collet Chuck
Cutting Process :
Milling Cutter
place of origin :
China
Description

BT ER tool holder material 20CrMnTi, wear-resistant and durable. Tool holder hardness 58-60 degrees, low noise, low wind resistance, high repetitive clamping accuracy. with ER20 cylinder clamp, the speed reaches 20000 revolutions.Bt Collet Chuck,Tool Holders For Cnc Machines.BT ER collet chuck tool holder is made of high quality material. It has good elasticity and wear resistance after heat treatment. It has high precision and stable performance. Mainly used in drilling, milling, reaming, tapping and grinding tool holder use.

BT40 ER25 Length70 Collet Tool Holder BT Tool Holder,ER Collet Chuck Precision Parts is a kind of numerical control tool holder, there are bt30, bt40, bt50, and there are many models, which are widely used. Used for boring, milling, drilling, tapping, grinding and carving. It is a common tool handle.ER COLLET CHUCK and ER COLLET, also known as spring chuck, Er nut, BT pull stud, ER COLLET CHUCK can be used to clamp milling cutters and taps.

BT ER spring chuck tool holder feature:
1.Material: 20CrMnTi BT Tool Holders
2.Production standard: MAS403 BT Tool Holders
3.Place of origin: Made in China
4.BT40= Taper shank taper 7:24 ; ER=The er collet specifiCATEEions; 100L= The length of the work.

5.BT ER collet chuck Material: hardened steel; processing machinery: CNC turning centers.

6. The cone angle AT3, tolerance: 8 ° 17'50 "± 5"

7. BT tool holder Accuracy <0.005

8. BT ER collet chuck Hardness: HRC56-62 °, carburizing depth: 1.0 ± 0.2

9. The through hole and a cooling tube (AD / B) design, can be customized according to customer demand.

ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
There are ER16-70, ER16-100 and ER16-150 in bt30. ER20-70, ER20-100, ER20-150. ER25-70, ER25-100, ER25-150. ER25-70, ER32-100, ER32-150.

BT40 has ER16-70, ER16-100, ER16-150. ER20-70, ER20-100, ER20-150. ER25-70, ER25-100, ER25-150. ER25-70, ER32-100, ER32-150. ER40-100, ER40-150

There are ER16-100 and ER16-150 in bt50. ER20-100, ER20-150. ER25-100, ER25-150. ER32-100, ER32-150. ER40-100, ER40-150

ER COLLET CHUCK is a kind of accessory for edge-jointing tool machine tool, also known as ER tool holder, which is used to install on the spindle of drilling, tapping, milling machine or machining center. It is a kind of fixed locking device for fixing and reinforcing parts that need to be reconstructed and processed.


ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150

MODEL L1 L D D1 T
BT30-ER16-70 70 118.4 28 31.75 M10*1.5
BT30-ER16-100 100 148.4 28 31.75 M10*1.5
BT30-ER16-120 120 168.4 28 31.75 M10*1.5
BT30-ER20-70 70 118.4 34 31.75 M12*1.75
BT30-ER20-100 100 148.4 34 31.75 M12*1.75
BT30-ER20-135 135 183.4 34 31.75 M12*1.75
BT30-ER25-70 70 118.4 42 31.75 M16*2
BT30-ER25-135 135 183.4 42 31.75 M16*2
BT30-ER32-70 70 118.4 50 31.75 M16*2
BT30-ER32-100 100 148.4 50 31.75 M16*2
BT30-ER40-80 80 128.4 63 31.75 M16*2
BT40-ER16-70 70 135.4 28 44.45 M10*1.5
BT40-ER16-100 100 165.4 28 44.45 M10*1.5
BT40-ER16-125 125 190.4 28 44.45 M10*1.5
BT40-ER16-160 160 215.4 34 44.45 M10*1.5
BT40-ER20-70 70 135.4 34 44.45 M12*1.75
BT40-ER20-100 100 170.4 34 44.45 M12*1.75
BT40-ER20-135 135 200.4 34 44.45 M12*1.75
BT40-ER20-160 160 215.4 34 44.45 M12*1.75
BT40-ER25-70 70 135.4 42 44.45 M16*2
BT40-ER25-100 100 165.4 42 44.45 M16*2
BT40-ER25-125 125 190.4 42 44.45 M16*2
BT40-ER25-160 160 215.4 42 44.45 M16*2
BT40-ER32-70 70 135.4 50 44.45 M16*2
BT40-ER32-100 100 165.4 50 44.45 M16*2
BT40-ER32-150 150 215.4 50 44.45 M16*2
BT40-ER40-80 80 145.4 63 44.45 M20*2
BT40-ER40-100 100 165.4 63 44.45 M20*3
BT40-ER40-120 120 185.4 63 44.45 M20*4
BT40-ER40-150 150 215.4 63 44.45 M20*5
BT40-ER50-85 85 145.4 78 44.45 M24*2
BT40-ER50-100 100 165.4 78 44.45 M24*2
BT50-ER16-70 70 171.8 28 69.85 M10*1.5
BT50-ER16-90 90 191.8 28 69.85 M10*1.5
BT50-ER16-105 105 206.8 28 69.85 M10*1.5
BT50-ER16-135 135 236.8 28 69.85 M10*1.5
BT50-ER16-165 165 266.8 28 69.85 M10*1.5
BT50-ER20-70 70 171.8 34 69.85 M12*1.75
BT50-ER20-90 90 191.8 34 69.85 M12*1.75
BT50-ER20-105 105 206.8 34 69.85 M12*1.75
BT50-ER20-135 135 236.8 34 69.85 M12*1.75
BT50-ER20-150 150 251.8 34 69.85 M12*1.75
BT50-ER20-165 165 266.8 34 69.85 M12*1.75
BT50-ER20-200 200 301 34 69.85 M12*1.75
BT50-ER25-70 70 171.8 42 69.85 M16*2
BT50-ER25-105 105 206.8 42 69.85 M16*2
BT50-ER25-135 135 236.8 42 69.85 M16*2
BT50-ER25-165 165 266.8 42 69.85 M16*2
BT50-ER32-80 80 181.8 50 69.85 M16*2
BT50-ER32-100 100 201.8 50 69.85 M16*2
BT50-ER32-120 120 221.8 50 69.85 M16*2
BT50-ER32-160 160 251 50 69.85 M16*2
BT50-ER32-200 200 301 50 69.85 M16*2
BT50-ER40-80 80 181.8 63 69.85 M20*2
BT50-ER40-100 100 201.8 63 69.85 M20*2
BT50-ER40-120 120 221.8 63 69.85 M20*2
BT50-ER40-135 135 236.8 63 69.85 M20*2
BT50-ER50-90 90 191.8 78 69.85 M24*2
BT50-ER50-120 120 221.8 78 69.85 M24*2
BT50-ER50-165 165 266.8 78 69.85 M24*2

ER Collet Chuck BT Tool Holder for ER16-70, ER16-100, ER16-150, ER20-70, ER20-100, ER20-150
