ISO9001 Alloy Medical Titanium Sheet Metal Thin Sheet For Automative Marine Energy
ISO9001 Alloy Medical Titanium Sheet Metal Thin Sheet For Automative Marine Energy
ISO9001 Alloy Medical Titanium Sheet Metal Thin Sheet For Automative Marine Energy
ISO9001 Alloy Medical Titanium Sheet Metal Thin Sheet For Automative Marine Energy
Specifications
Brand Name :
BaseTi
Model Number :
THB008
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
12~20 days
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Heat treatment options :
Annealing, Normalizing
Production standards :
ASTM B265, ASME SB-265, ISO 5832
Grade :
Ti-6Al-4V, Ti-6Al-7Nb, Ti-3Al-2.5V, Grade 5, Grade 9
Hardness :
Varies depending on grade
Melting Point :
Typically around 1,660°C (3,020°F)
Density :
4.43–4.51 g/cm^3
Tolerance :
Thickness: +/- 0.1mm; Width: +/- 0.5mm; Length: +/- 1.0mm
Rolling process :
Hot rolling, Cold rolling
Surface process :
Polished, Sandblasted, Pickled
Size :
Thickness: 5-200mm; Width: 500-3000mm; Length: 1000-12000mm
Description

Alloy Titanium Plate Sheet For Petrochemical Industry For Aerospace Automotive Medical Marine Energy

Alloy Titanium Plate - OVERVIEW

*If you have any requirements for customized titanium plate, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Titanium plate specifications & parameters

Product name

Titanium plate sheet

Application field

Aerospace, Automotive, Shipbuilding, Defense, Structural Engineering

Available size

Thickness: 5-200mm; Width: 500-3000mm; Length: 1000-12000mm

Grade

Ti-6Al-4V, Ti-6Al-7Nb, Ti-3Al-2.5V, Grade 5, Grade 9

Production stadards

ASTM B265, ASME SB-265, ISO 5832

Tolerance

Thickness: +/- 0.1mm; Width: +/- 0.5mm; Length: +/- 1.0mm

Hot rolling, Cold rolling

Rolling process

Hot rolling, cold rolling

Surface process

Polished, Sandblasted, Pickled

Delivery time

12-16days

Key words

Titanium Alloy Plates, Aerospace, Automotive, Medical, Marine, Energy Sector, ASTM F136, Corrosion Resistance, High-Temperature Resistance,

Alloy Titanium Plate & Advantage

The Transformative Role of Titanium Alloy Plates Across Various Industries
Titanium alloy plates are not merely an option but a necessity across multiple sectors, owing to their unparalleled advantages in terms of strength, corrosion resistance, and heat tolerance. Below is an expert overview detailing how Titanium alloy plates can be a solution to various challenges in different industries.

  • Aerospace Industry

Titanium alloy plates are ideal for aircraft components due to their high strength-to-weight ratio. In fact, data shows that the use of titanium in modern jet engines can reduce weight by up to 30%.

  • Automotive Industry

The alloy's excellent wear resistance makes it ideal for use in automotive parts, thus increasing the lifespan of the vehicle. In electric vehicles, a lighter weight translates to extended battery life.

  • Medical Industry

The biocompatible nature of Titanium makes it an excellent material for surgical implants. According to studies, titanium alloys like Ti-6Al-4V meet the ASTM F136 standard for surgical applications.

  • Marine Applications

With remarkable corrosion resistance, especially in saltwater conditions, Titanium plates are extensively used in shipbuilding and sub-sea technologies.

  • Energy Sector

The alloy's high-temperature resistance makes it suitable for applications in the nuclear industry, providing excellent long-term performance.

BaseTi's Offering
BaseTi specializes in providing high-quality Titanium alloy plates conforming to various industry standards, delivering reliability, and boosting performance across all sectors.

ISO9001 Alloy Medical Titanium Sheet Metal Thin Sheet For Automative Marine Energy

Alloy Titanium Plate of Pysical Properties
Grade ASTM Standard Tensile Strength (psi) Yield Strength (psi) Elongation (%) Hardness (HV) Thermal Conductivity (W/mK) Density (g/cm³)
Ti6Al4V (Grade 5) ASTM B265, ISO 5832 130,000 – 150,000 120,000 10 - 15 330-370 6.7 4.43
Ti3Al2.5V (Grade 9) ASTM B265, ISO 5832 90,000 – 120,000 70,000 15 - 20 300-340 7.2 4.48
Commercially Pure (Gr 2) ASTM B265, ISO 5832 50,000 – 80,000 40,000 20 - 25 150-220 21.9 4.51

This tabulation incorporates several crucial parameters including tensile strength, yield strength, elongation, hardness, thermal conductivity, and density, providing a 360-degree view of the material properties under various grades and standards such as ASTM B265 and ISO 5832. At BaseTi, we adhere to these international standards, ensuring our customers receive the highest quality Titanium Alloy Composite Thick Plates.

ti metal thin sheet for Marine Energy 3
