Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage
Specifications
Brand Name :
BaseTi
Model Number :
THB004
Certification :
ISO 9001, AS9100
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15~20 days
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Mechanical Properties :
Tensile Strength: 240 MPa min, Yield Strength: 170 MPa min
Production standards :
ASTM B265, AMS4900
Grade :
Grade 1
Heat Treatment :
Annealed for improved ductility.
Tolerance :
Thickness +/- 0.03mm; Width +/- 0.2mm; Length +/- 0.5mm.
Rolling process :
Hot-rolled and Cold-rolled options available.
Surface process :
Sandblasted, pickled, or polished.
Description

Grade 1 AMS4900Pure Titanium Plate For Petrochemical Industry, Including Refining, Fluid Transport, Chemical Storage

Pure Titanium Plate - OVERVIEW

*If you have any requirements for customized pure titanium plate, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Titanium plate specifications & parameters
Product name Grade 1 AMS4900Pure Titanium Plate
Application field Aerospace, Medical Devices, Chemical Processing
Available size Thickness: 0.5-100mm, Width: 1000-2000mm, Length: 2000-6000mm
Grade Grade 1
Production stadards ASTM B265, AMS4900
Tolerance Thickness: ±0.1mm, Width: ±0.5mm, Length: ±1.0mm

Rolling process Hot Rolled, Cold Rolled
Surface process Pickling, Polished, Sandblasted
Delivery time 12-16days
Key words
  • Pure Titanium Plate of Grade 1
  • Aerospace
  • Medical Devices
  • Chemical Processing
  • Tensile Strength
  • Yield Strength
  • Corrosion Resistance
  • ASTM B265
  • AMS4900

Grade 1 Pure Titanium Plate & Solutions

Pure Titanium Plate of Grade 1: Industry Solutions and Applications
When it comes to high-performance materials, Pure Titanium Plate of Grade 1 stands out for its unique properties. Manufactured to the highest standards by BaseTi, this exceptional material is ideal for various applications across industries.

  • Aerospace

In the aerospace sector, Titanium Grade 1 plates are highly valued for their low density and high strength-to-weight ratio. With a tensile strength of 240 MPa and a yield strength of 170 MPa, these plates offer superior performance in aircraft construction.

  • Medical Devices

In medical applications, the biocompatibility of Grade 1 Titanium makes it an ideal choice for surgical implants and dental appliances. Recent data indicates that Titanium implants have a success rate of over 98%.

  • Chemical Processing

In the chemical industry, these plates are lauded for their excellent resistance to corrosion, especially in acidic environments. They can sustain prolonged exposure to chemicals without degradation, making them a staple in this field.

BaseTi: Your Reliable Titanium Manufacturer
Trust BaseTi for delivering Grade 1 Titanium plates that meet all industry standards, including ASTM B265 and AMS4900. Our state-of-the-art manufacturing facilities ensure the highest quality for all your industrial needs.

Grade 1 AMS4900 Pure Thin Titanium Sheet For Fluid Transport Chemical Storage

Grade 1 Pure Titanium Plate of Pysical Properties
Property
 Grade 1 Grade 2 Grade 3 Grade 4 ASTM Standard
Density (g/cm³) 4.51 4.51 4.51 4.51 ASTM B265
Tensile Strength (psi) 35,000 50,000 65,000 80,000 ASTM B265
Yield Strength (psi) 25,000 40,000 55,000 70,000 ASTM B265
Elongation (%) 24 20 18 15 ASTM B265
Melting Point (°C) 1,668 1,668 1,668 1,668 ASTM B265
Thermal Conductivity (W/m·K) 21.9 21.9 21.9 21.9 ASTM B265
Coefficient of Thermal Expansion (10⁻⁶/°C) 8.6 8.6 8.6 8.6 ASTM B265
Electrical Resistivity (μΩ·cm) 55.0 55.0 55.0 55.0 ASTM B265

From an expert's viewpoint, the physical properties of Pure Titanium Plates adhere strictly to ASTM B265 standards, making them reliable choices for industrial applications. The tensile and yield strengths vary by grade, offering flexibility in selecting the right material for specific projects.
