10mm To 25mm Medical Pure Titanium Disk Dental Titanium Alloy Disc Grade 2 3 5
10mm To 25mm Medical Pure Titanium Disk Dental Titanium Alloy Disc Grade 2 3 5
10mm To 25mm Medical Pure Titanium Disk Dental Titanium Alloy Disc Grade 2 3 5
10mm To 25mm Medical Pure Titanium Disk Dental Titanium Alloy Disc Grade 2 3 5
Specifications
Brand Name :
BaseTi
Model Number :
TYP011
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
12~20 days
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Production standards :
ASTM F136 ASTM F67 (USA), EN ISO 5832-3 EN ISO 5832-2 (Europe)；
Material Grade :
Grade 2，Grade 3，Grade 5
Corrosion Resistance :
Excellent, ASTM F2129 compliant
Application Field :
Dental Implants, Crowns, Bridges
Mechanical Strength :
950-1000 MPa tensile strength
Biocompatibility :
ISO 10993-1 compliant
Diameter and Thickness :
Diameter and Thickness: 98mm x 10-25mm in stock
Ti Disc Tolerance :
+/-0.05 mm or customized
Description

Stock Size Φ98mm*10mm ~ 25mm, Medical Pure Titanium Disc, Dental Titanium Alloy Disc ASTM F136 ASTM F67 Grade 2 3 5

BaseTi Grade 2,3,5 Dental Titanium Disc Status - Instock NOW
BaseTi - Dental Pure Titanium Disc Inventory
Grade Stock Size Weight(kg)
ASTM Grade 2
ASTM Grade 3		 Φ98mm*10mm 0.34
Φ98mm*12mm 0.41
Φ98mm*14mm 0.48
Φ98mm*16mm 0.54
Φ98mm*18mm 0.61
Φ98mm*20mm 0.68
Φ98mm*22mm 0.75
Φ98mm*24mm 0.82
Φ98mm*25mm 0.85
　
BaseTi - Dental Titanium Alloy Disc Inventory
Grade Stock Size Weight(kg)
ASTM Grade 5
Ti-6Al-4V		 Φ98mm*10mm 0.34
Φ98mm*12mm 0.41
Φ98mm*14mm 0.48
Φ98mm*16mm 0.54
Φ98mm*18mm 0.61
Φ98mm*20mm 0.68
Φ98mm*22mm 0.75
Φ98mm*24mm 0.82
Φ98mm*25mm 0.85

*The dimensions listed in the table above represent the sizes we regularly supply, and we have ample stock available.

*Should you require customized dimensions for your titanium discs, or specific tolerance parameters, we are able to complete production within a swift timeframe of 10 to 15 days.

Grade 2,3,5 Dental Titanium Disc - Guide

A Buyer's Guide: Navigating Dental Titanium Disc Grades and Applications

Overview
The choice of material in the dental domain can significantly influence the final outcome. Dental Titanium Discs, renowned for their unmatched biocompatibility and durability, stand out in this aspect. This guide serves as a compass for overseas purchasers, simplifying the intricacies of titanium grades and their dental applications.

Diving into Material Grades and Standards
Selecting the apt grade is paramount, ensuring adherence to dental application standards. While the U.S. leans on ASTM F67 and ASTM F136 for regulatory guidance, Europe relies on EN ISO 5832-2 and EN ISO 5832-3.

  • ASTM Grade 2 (Pure Titanium Dental Disc)

Composition: Pure Titanium
Guidelines: ASTM F67, EN ISO 5832-2
Utilization: Crafting dental crowns and bridges
Supplier: BaseTi

  • ASTM Grade 3

Composition: Enhanced Pure Titanium
Guidelines: ASTM F67, EN ISO 5832-2
Utilization: Ideal for implant abutments and frameworks

  • ASTM Grade 5 (Ti Dental Milling Disc)

Composition: Titanium Alloy (Ti6Al4V)
Guidelines: ASTM F136, EN ISO 5832-3
Utilization: High-load-bearing implants and advanced orthodontic tools

Spotlight on Applications
Exploring the niche applications in dentistry:

  • Dental Crowns and Bridges (ASTM Grade 2)

Sourced from BaseTi, the ASTM Grade 2 Pure Titanium Discs are tailored for dental crowns and bridges, ensuring longevity and ease in milling.

  • Implant Abutments (ASTM Grade 3)

With superior strength, ASTM Grade 3 becomes the material of choice for dental implant abutments without compromising on biocompatibility.

  • Orthodontic Devices and High-Load Implants (ASTM Grade 5)

For demanding applications like high-load implants and intricate orthodontic devices, BaseTi's Grade 5 Titanium Discs, made of Ti6Al4V alloy, prove ideal.

Why Opt for BaseTi?
*Elevating the standards as a premier titanium factory and titanium manufacturer, BaseTi specializes in premium Dental Titanium Alloy Discs and Dental Implant Discs. Catering to diverse needs, BaseTi is the ultimate destination for dental titanium solutions.

*Harnessing the potential of Dental Titanium Discs requires an understanding of their grade and application. Be it dental bridges, crowns, or advanced orthodontic tools, the right grade is pivotal for achieving excellence.

10mm To 25mm Medical Pure Titanium Disk Dental Titanium Alloy Disc Grade 2 3 5
Production Standards for Dental Titanium Disc

Attribute

ASTM Grade 2
ASTM Grade 3

ASTM Grade 5

U.S. Standards

ASTM F67

ASTM F67

ASTM F136

European Standards

EN ISO 5832-2

EN ISO 5832-2

EN ISO 5832-3

Material

Pure Titanium

Pure Titanium (more alloyed than Grade 2)

Titanium Alloy (Ti6Al4V)

Applications

Dental crowns, bridges

Dental implants, abutments

High-load-bearing implants, complex dental prosthetics

Specific Products

Dental Crowns and Bridges, Less-load-bearing dental implants

Dental Implants and Abutments, more load-bearing compared to Grade 2

Complex Dental Prosthetics, High-load-bearing dental implants

Physical Properties of Dental Titanium Discs

The physical properties of dental titanium discs vary depending on the grade of the material and the respective standards they meet. Below is a comprehensive table that encapsulates these vital features:

Attribute ASTM F67 (U.S.) ASTM F136 (U.S.)
EN ISO 5832-2 (EU)
 EN ISO 5832-3 (EU)
Grade Grade 2 Grade 5 Grade 2 Grade 5
Density (g/cm³) 4.51 4.43 4.51 4.43
Tensile Strength (MPa) 345-450 930-1030 345-450 930-1030
Yield Strength (MPa) 275-450 860-880 275-450 860-880
Elongation (%) 20 10-16 20 10-16
Hardness (HV) 120-180 350-440 120-180 350-440

Chemical Properties of Dental Titanium Discs
For a comprehensive understanding of dental titanium discs, it's crucial to explore their chemical properties as well. Below is a table that does just that:

Element
ASTM F67
Grade 2 (%)

ASTM F136

Grade 5 (%)

EN ISO 5832-2

Grade 2 (%)

EN ISO 5832-3

Grade 5 (%)

C

≤ 0.10

≤ 0.08

≤ 0.10

≤ 0.08

O

≤ 0.25

≤ 0.20

≤ 0.25

≤ 0.20

N

≤ 0.03

≤ 0.05

≤ 0.03

≤ 0.05

H

≤ 0.015

≤ 0.012

≤ 0.015

≤ 0.012

Fe

≤ 0.30

≤ 0.25

≤ 0.30

≤ 0.25

Al

--

5.5-6.75

--

5.5-6.75

V

--

3.5-4.5

--

3.5-4.5
