1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business
Specifications
Condition :
New
Spindle Taper :
BT50
No. of Spindles :
Single
Type :
Horizontal
Dimension(L*W*H) :
5800x4800x3800mm
Weight (T) :
14 T
Table Size (mm) :
800x800
CNC Control System :
GSK, FANUC, MITSUBISHI, KND, Siemens
Number of Axes :
3
Table Travel (X) (mm) :
1600
Table Travel (Y) (mm) :
1000
Table Travel (Z) (mm) :
1000
Positioning Accuracy (mm) :
±0.002
Repeatability (X/Y/Z) (mm) :
±0.002
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
18.5
Max. Table Load(kg) :
2500 kg
Min. Time of Tool Change(s) :
6
Tool Magazine Capacity :
40
Key Selling Points :
High-accuracy
Warranty :
12 Months, 1 year
Place of Origin :
China
Brand Name :
Timeway
Voltage :
Choiced
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Machine Type :
Horizontal machining center
Control system :
FANUC or SIEMENS or others
Loading capacity :
2500kg
Spindle speed :
6000rpm
ATC :
Chain 40pcs
Weight :
14000kg
X axis travel :
1600mm
Y axis travel :
1000mm
Number of axes :
3 axes
Applicable Industries :
Building Material Shops, Manufacturing Plant, Other
Showroom Location :
Brazil, Russia, Romania, Uzbekistan
Core Components :
Motor
Rapid Feed Speed(m/min) :
X:12 Y:12 Z:12
Packaging Details :
Wooden pallet or box
Port :
China ports
Supply Ability :
100 Set/Sets per Month
Price :
$80,000.00/sets >=1 sets
MOQ :
1 set
Description

Horizontal Machining Center HMC

H8

1600mm Table Travel HMC H8 Advanced Horizontal Machining Center for Your Business

Product Description

Technical parameter:

Techncial parameters Unit H8
Wortable size mm 800x800
Worktable number - 1
Worktable indexing ° 1°
Worktable loading capacity kg 2500
T slot of worktable (No.-sizexdistance) - 5-20x160
X axis travel mm 1600
Y axis travel mm 1000
Z axis travel mm 1000
Distance from spindle center to worktable mm 0-1000
Distance from spindle nose to wortable center mm 180-1180
Spindle taper (Style/diameter) - BT50-Φ190
Max. spindle speed rpm 6000
ATC style/station - Chain/40pcs
Max. tool diameter mm 400
Max. tool length mm Φ127
Max. tool weight kg 20
X/Y/Z Rapid moving speed m/min X:12 Y:12 Z:12
X/Y/Z Rail style - Sliding
Main motor kw 15-18.5
X/Y/Z Feeding motor NM X:30 Y:30 Z:30
Net weight (appox.) kg 14000
Overall dimension (LxWxH) mm 5800x4800x3800

Main configuration & accessories:
1. Resin sand casting;
2. X, Y, Z rails adopts imported linear guideway, H6/H8 are quenching - plastic sliding guide rail pair;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle, H3 is direct driven spindle;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC,disc type and chain type are available as option;
7. Imported bearings for leadsrews;
8. Import coupling;
9. Headstock balancing system have nitrogen balance system or hydraulic balance system as option;
10. NC rotary worktable (B axis);
11. Work lamp;
12. Pilot lamp;
13. USB and Internet interface;
14. Manual pulse generator (MPG);
15. Centralized automatic lubrication system.
16. Cooling system.
17. Heat exchanger for electrical cabinet ;
18. Leveling blocks & bolts;
19. Toolbox and tools;
20. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
Optional configuration & accessories:
1. ZF or BF reducer;
2. Circular Coolant Nozzle;
3. Coolant through spindle (CTS);
4. Spindle oil cooler;
5. Air conditioner (A/C) for electrical cabinet;
6. Auto. Tool length measurement system;
7. Auto. Workpiece measurement systems;
8. Chain type chip conveyor;
