1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
Specifications
Condition :
New
Spindle Taper :
BT50
No. of Spindles :
Single
Type :
Horizontal
Dimension(L*W*H) :
6580*3580*2570mm
Weight (T) :
12 T
Table Size (mm) :
800*800
CNC Control System :
GSK, FANUC, Siemens
Number of Axes :
3
Table Travel (X) (mm) :
1800
Table Travel (Y) (mm) :
1400
Table Travel (Z) (mm) :
900
Positioning Accuracy (mm) :
0.008 mm
Repeatability (X/Y/Z) (mm) :
0.005
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
15/18.5
Max. Table Load(kg) :
2000 kg
Feed Speed(mm/min) :
1 - 8000 mm/min
Min. Time of Tool Change(s) :
0.5
Tool Magazine Capacity :
16, 12, 24
Key Selling Points :
Multifunctional
Warranty :
1 Year
Place of Origin :
Henan, China
Brand Name :
Timeway
Voltage :
customized
Marketing Type :
New Product 2020
Machinery Test Report :
Not Available
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Table size :
800*800
Product name :
CNC Machining Center
Machine Type :
Cnc Horizontal Machining Center
Application :
Metal Machining Center
Keywords :
Horizontal Machine Cetner
CNC or Not :
CNC Systemn
Color :
Custom-made
The number of axis :
3
X-axis travel :
1800
Y-axis travel :
1400
Showroom Location :
None
Core Components :
Motor
Rapid Feed Speed(m/min) :
24
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Energy & Mining, metal machining
Price :
$34,500.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
CNC Milling Machine---Horizontal Machining Center
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power

Standard accessories:

√ FANUC 0i MF CNC system
√ X/Y: Linear guide rails, Z: Sliding guide rail
√ Taiwan BT40 spindle, 8000rpm
√ Taiwan disc-type ATC with 24tools
√ Full enclosure
√ Manual pulse generator (MPG)
√ USB & LAN interface
√ Work lamp
√ Pilot lamp
√ Cooling system
√ Centralized automatic lubrication system
√ Spindle air blast
√ Air gun
√ Milling arbor & chuck
√ Heat exchanger for electric cabinet
√ Tools & tool-box
√ Leveling wedge & bolts
√ Operation manual (English)

Optional accessories:

_MITSUBISHI/SIEMENS/FAGOR/GSK/HNC/KND
_ 4th axis
_ Direct driven spindle (10000, 12000, 15000rpm)
_ Circular coolant nozzle
_ Coolant through spindle (CTS)
_ Spindle oil cooler
_ Air conditioner
_ Chain-type chip conveyor
_ Water gun
_ Safety door
_ Tool measurement system
_ Workpiece measurement system
Specification
Specification
Unit
HMC800S
B-axis servo motor torque(FANUC)
-
20
Table indexing
°
1°x360
T-slots (No./width/pitch)
-
5-22-165
Table rotation speed
rpm
11.1
Loading capacity
kg
2000
Locking force(35kg/cm2)
kg/m
5000
X/Y/Z-axis rapid feed speed
m/min
24/12/18
B-axis positioning accuracy
''
10''
ATC capacity (style)
tools
40(Chain)
Max. tool weight
kg
20
Max. tool diameter
mm
125/230
Max. tool length
mm
300
Air pressure require
kg/cm2
8
Detailed Images
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
Recommend Products
Company Profile
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
Business Range: Industrial Equipment & Components, Manufacturing & Processing Machinery Main Products: Lathe , Milling Machine , Drilling Machine , Grinding Machine , CNC Machines , Shearing Machine , Press Brakes , Rolling Machine , Forklift Truck , Vehicle Machine Management System Certification: ISO 9001, ISO 14001
1800mm Table Travel CNC Milling Machine Equipped with 15/18.5kW Spindle Motor Power
FAQ
1. who are we?
We are based in Henan, China, start from 2010,sell to South America(20.00%),Africa(15.00%),Eastern Europe(15.00%),South Asia(10.00%),North America(10.00%),Oceania(10.00%),Western Europe(10.00%),Southeast Asia(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Lathe, CNC Lathe, CNC Milling Machine, Machining Center, Grinding Machine

4. why should you buy from us not from other suppliers?
Our factory have more than 50years experience of researching & producing lathe and heavy duty lathe, both conventional and CNC types, normal use and special use, etc.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
