SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Specifications
Condition :
New
Spindle Taper :
BT30
No. of Spindles :
Single
Type :
Gantry
Dimension(L*W*H) :
7750*5140*4100mm
Weight (T) :
42 T
Table Size (mm) :
3000*2300
CNC Control System :
GSK, FANUC, MITSUBISHI, KND, Siemens
Number of Axes :
5
Table Travel (X) (mm) :
3000
Table Travel (Y) (mm) :
2700
Table Travel (Z) (mm) :
1000
Positioning Accuracy (mm) :
0.005
Repeatability (X/Y/Z) (mm) :
0.003
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
22/26
Max. Table Load(kg) :
10000 kg
Min. Time of Tool Change(s) :
4
Tool Magazine Capacity :
24
Key Selling Points :
Competitive Price
Warranty :
1 Year
Place of Origin :
Henan, China
Brand Name :
timeway
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Product name :
Gantry CNC Machining Center
Machine Type :
Gantry Milling Machine
Model :
GMC2700
CNC or Not :
CNC Systemn
Control system :
SIEMENS GSK FANUC (optional)
Color :
Customer's Requirement
After-sales Service Provided :
1 Year
Spindle Speed :
6000 Rpm
Worktable size :
3000*2300mm
X/Y/Z Axis Travel :
3000/2700/1000mm
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Printing Shops, Construction works
Showroom Location :
Saudi Arabia, Russia, South Korea, Bangladesh
Core Components :
Motor
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$198,000.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
Gantry type Machining Center
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Specification
Specification
Unit
GMC2200
GMC2700
Table width
mm
2000
2300
T-slot (No./width/pitch)
mm
9/22/200
11/28/200
Cross travel (Y)
mm
2200 (2700)
2700 (3050)
Vertical travel (Z)
mm
1000
1000
Gantry width
mm
2300
2700
Max. height of workpiece
mm
1400
1400
Accessories

Standard accessories：

▪ CNC controller: GSK
▪ Semi-Enclosed Splash Guard
▪ Work Lamp
▪ Alarm Lamp
▪ High Pressured Coolant & Air Gun
▪ Spindle Air Blast & Coolant Nozzle
▪ Rigid Tapping
▪ Auto Lubrication System
▪ USB & RS232
▪ Heat exchanger for electrical cabinet
▪ Editable CF Card Function
▪ Hand Wheel (MPG)
▪ Auto interrupt & Power Off System
▪ Chain Type Chip Conveyor + trolley
▪ Spindle oil cooler
▪ Leveling Blocks & Screws
▪ Tool & Tool Box
▪ Operation manual

Optional accessories：

▪ FANUC 0i MF/ SIEMENS 828D
▪ Special milling head
▪ Circular Coolant Nozzle
▪ Coolant through spindle (CTS)
▪ Spindle oil cooler
▪ Auto. Tool length measurement system
▪ Auto. Workpiece measurement systems
Client feedback
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining

This picture is the customer's favorable feedback to us. A picture can't mean anything, but we insist on the quality of the machine, we believe that repeat customers will be more and more.
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Factory Display：
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
SIEMENS/GSK/FANUC Control Speed Gantry CNC Milling Machine for High Precision Machining
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
