4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
Specifications
Condition :
New
Spindle Taper :
BT-50
No. of Spindles :
3
Type :
Horizontal
Dimension(L*W*H) :
4285*3120*3280
Weight (T) :
8 T
Table Size (mm) :
630x630
CNC Control System :
GSK, FANUC, KND, Siemens
Number of Axes :
3
Table Travel (X) (mm) :
1000
Table Travel (Y) (mm) :
750
Table Travel (Z) (mm) :
600
Positioning Accuracy (mm) :
±0.008
Repeatability (X/Y/Z) (mm) :
±0.005
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
15/18.5
Max. Table Load(kg) :
1200 kg
Min. Time of Tool Change(s) :
2
Tool Magazine Capacity :
24
Key Selling Points :
Competitive Price
Warranty :
1 Year
Place of Origin :
Henan, China
Brand Name :
TIMEWAY
Marketing Type :
Hot Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Product name :
Horizontal Machining Center
Table size :
630x630mm
Table rotation speed :
11.1rpm
Loading capacity :
1200kg
Spindle speed :
6000rpm
Main motor power :
15/18.5kw
ATC capacity (style) :
24 (Disc) tools
Machine weight :
8000kg
Power supply :
40Kva
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining, Food & Beverage Shops
Showroom Location :
Egypt, Canada, United States, Germany, Indonesia, India, Mexico, Spain, Thailand, South Korea, South Africa, Japan, Australia
Core Components :
Motor
Price :
$35,600.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine
Product Description
4285*3120*3280 CrossType HMC630S CNC Horizontal Machining Center for CNC Milling Machine

MAIN CONFIGURATION & ACCESSORIES:

1. Resin sand casting;
2. X, Y, Z rails adopts imported linear guideway, Y-axis adopts quenching - plastic sliding guide rail pair for HMC630S, HMC800S;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC,disc type and chain type are available as option;
7. Imported bearings for leadscrews;
8. Imported coupling;
9. Headstock balancing system have nitrogen balance system or hydraulic balance system as option;
10. NC rotary worktable (B axis);
11. Work lamp;
12. Pilot lamp;
13. USB and LAN interface;
14. Manual pulse generator (MPG);
15. Centralized automatic lubrication system.
16. Cooling system.
17. Heat exchanger for electrical cabinet ;
18. Leveling blocks & bolts;
19. Toolbox and tools;
20. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.

OPTIONAL CONFIGURATION & ACCESSORIES:

1. ZF or BF reducer;
2. Circular Coolant Nozzle;
3. Coolant through spindle (CTS);
4. Spindle oil cooler;
5. Air conditioner (A/C) for electrical cabinet;
6. Auto. Tool length measurement system;
7. Auto. Workpiece measurement systems;
8. Optional with sprial type chip conveyor and chain type chip conveyor.
Specification
SPECIFICATION
UNIT
HMC630S
Machine structure
-
Cross-type
X-axis travel
mm
1000
Y-axis travel
mm
750
Z-axis travel
mm
600
B-axis servo motor torque (FANUC)
-
15
Table size
mm
630×630
Table indexing
°
1°×360
T-slots (No./width/pitch)
-
5-18-122
Table rotation speed
rpm
11.1
Loading capacity
kg
1200
Locking force (35kg / cm2)
kg/m
4000
Distance spindle center to table
mm
50-800
Distance spindle nose to table center
mm
50-650
Spindle taper
-
BT-50
Spindle speed
rpm
6000
Main motor power
kw
15/18.5
X/Y/Z-axis servo motor (FANUC)
-
Bis22/Bis22/Bis22
X/Y/Z-axis cutting feed speed
mm/min
1-8000
X/Y/Z-axis rapid feed speed
m/min
24/15/24
X/Y/Z-axis rails type
-
X/Z: Linear/Y: sliding
X/Y/Z-axis positioning accuracy
mm
±0.008
X/Y/Z-axis repeat positioning accuracy
mm
±0.005
B-axis positioning accuracy
"
±10"
ATC capacity (style)
tools
24 (Disc)
Tool change time (tool to tool)
sec
5
Max. tool weight
kg
18
Max. tool diameter
mm
Φ112/Φ200
Max. tool length
mm
300
Power supply
Kva
40
Air pressure require
kg/cm2
8
Machine weight
kg
8000
Overall dimension (LxWxH)
mm
4285×3120×3280
