THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
Specifications
Brand Name :
THLB
Model Number :
24V20Ah LiFePO4 Battery
Place of Origin :
China
MOQ :
2 pieces
Price :
$98/pieces 10-49 pieces
Packaging Details :
Standard Packaging
Delivery Time :
7-15 Working Days
Payment Terms :
T/T
Type :
LIFEPO4
Voltage :
24V
Capacity :
20Ah
Category :
Rechargeable Batteries pack
Cell Configuration :
LiFePO4 26650 3.2V 3200mAh-8S7P
Cycle Characteristic :
2000 times
Working Temperature :
-20°C~60°C
Battery Weight :
2.9±0.2 kg
Reference Battery Size :
(168±1)*(128±1)*(102±1) mm
Warranty :
1 year
Description
THLB Deep Cycle Solar Battery 12V 24V 100Ah 200Ah 600Ah LiFePO4 Battery Pack
2000+ cycle rechargeable deep cycle solar energy storage lithium iron phosphate battery pack designed for reliable power in solar applications.
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
Main Kit Components
1 x 24V20Ah LiFePO4 Battery Module 1 x 4S-20A PCM
1 x Plastic Battery Case 2 x M8 Terminals
Product Specifications
Normal Voltage 24V
Normal Capacity 20Ah
Battery Energy 480Wh
Inner Resistance < 60mΩ
Battery Cycle Life 2000 Times @100%DOD
6000 Times @80%DOD
Cell Configuration LiFePO4 26650 3.2V 3200mAh-8S7P
Reference Battery Size (168±1)*(128±1)*(102±1) mm
Reference Battery Weight 2.9±0.2 kg
Battery Encapsulation Plastic Case
Charge Voltage 28.8V
Charge Mode CC/CV
Normal Charge Current <=50A
Normal Discharge Current 10A
Max. Continuous Output Current 20A
Max. Continuous Output Power 480W
Passive Protection Function Over charge protection; Over discharge protection; Over current protection, etc
Operation Temperature Range Charge: 0°C---45°C
Discharge: -20°C---60°C
Battery Storage Temperature -20°C---25°C
Individual Cell Approval CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS
Safety Performance Classification
  • Resistance to heavy loads - tested to not ignite or explode
  • Resistance to thermal shock - tested to not ignite or explode
  • Anti-overcharge - tested to not ignite or explode
  • Resistance to overdischarge - tested to not ignite or explode
  • Resistance to short circuit - tested to not ignite or explode
  • High temperature storage - tested to not leak, smoke, catch fire or explode
  • Anti-heating - tested with no explosion battery penetration
  • Anti-puncture - tested to not ignite or explode
  • Anti-extrusion - tested to not ignite or explode
  • Resistance to low pressure - tested to not leak, smoke, catch fire or explode
  • Constant damp heat - maintains capacity and appearance integrity
  • Anti-vibration - maintains functionality and appearance
  • Anti-collision - maintains functionality and appearance
  • Temperature cycling - maintains capacity and structural integrity
  • Flame retardant properties - meets GB/T2408-2008 standards
  • Insulation resistance - meets safety requirements for metal cases
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack

THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack

THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
Our Company
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
Packing & Delivery
THLB Deep Cycle Solar Battery 12v 24v 100ah 200ah 600ah Lifepo4 Battery Pack
Frequently Asked Questions
Q1. Can I have few free samples for evaluation?
A: Yes, free samples are ok, but not covering shipping cost
Q2. What about the lead time?
A: Samples needs 3-5 days
B: Mass production time is approx 2-3 weeks
Q3. Do you have any MOQ limit for bulk order?
A: MOQ=100pcs
Q4. How do you ship the goods and how long does it take to arrive?
A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days
B: Big quantity bulk order: Air shipping or Sea shipping
Q5. How to proceed an order for Lithium ion cell?
A: Pls confirm the cell models that you are interested in
B: We send cell specifications and best quotation to you for reference
C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly
D: After deposit or full payment confirmed, production started
Q6. Is it OK to print my logo on lithium ion cell product?
A: Yes. OEM is welcomed
Q7: Do you offer guarantee for the products?
A: Yes, 3-5 Years Warranty
