Specifications
Brand Name :
THLB
Model Number :
8IfR25.6-60-Y
Place of Origin :
China
MOQ :
10 pieces
Price :
$460/pieces 10-49 pieces
Application :
Home Appliances, Consumer Electronics, Boats, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs
Type :
LiFePo4
Voltage :
24V
Capacity :
60Ah
Category :
Rechargeable Batteries pack
Cell Configuration :
26650-3.2V-8S64P
Cycle Characteristic :
2000 times
Working Temperature :
-20°C~60°C
Size :
314*240*215mm
Color :
Black
Warranty :
1years
Anode Material :
LFP
Electric Energy :
1536 Wh
Packaging Details :
Standard Packaging
Delivery Time :
7-15 Working Days
Description
2000 Cycles Lithium Battery 24V 60Ah LiFePO4 Energy Storage Battery Pack Perfect for Industrial Power Storage Solutions
Product Parameters
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
Product Name
LiFePO4 battery pack
Product Model
25.6V60Ah
Specifications
8ITR25.6-60-Y
Composition
26650-3.2V-8S64P
Nominal Voltage
25.6V
Rated Capacity
200±3Ah
Energy
1.5kwh
Size
314*240*215mm
Voltage
Charge voltage is:28.8±0.2V;
Standard cutoff voltage is about 20V
Charger Current
≤30A
Discharge Current
≤60A
Communication
CAN/LCD DISPLAY
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery

Safety performance classification

(1) Resistance to heavy loads. The battery pack shall be tested according to the regulations and shall not ignite or explode.

(2) Resistance to thermal shock. The battery pack shall be tested according to the regulations and shall not ignite or explode.

(3) Anti-overcharge. The battery module shall be tested according to the regulations and shall not ignite or explode.

(4) Resistance to overdischarge. The battery module shall be tested according to the regulations and shall not ignite or explode.

(5) Resistance to short circuit. The battery module shall be tested according to the regulations and shall not ignite or explode.

(6) High temperature storage. The battery shall be tested according to the regulations and shall not leak, smoke, catch fire or explode.

(7) Anti-heating. The battery module is tested according to the regulations. No part of the explosion battery penetrates the screen, and some or all of the batteries protrude from the screen.

(8) Anti-puncture. The battery pack shall be tested according to the regulations and shall not ignite or explode.

(9) Anti-extrusion. The battery module shall be tested according to the regulations and shall not ignite or explode.

(10) Resistance to low pressure. The battery pack shall be tested in accordance with regulations and shall not leak, smoke, catch fire or explode.

(11) Constant damp heat. After the battery pack is tested according to the regulations, its appearance shall be free from obvious deformation, rust, smoke or explosion, and its capacity shall not be less than 90% of the rated value.

(12) Anti-vibration. The battery pack shall be tested according to the regulations, and its appearance shall be free from obvious damage, liquid leakage, smoke or explosion, and it can work normally.

(13) Anti-collision. The battery pack shall be tested according to the regulations, and its appearance shall be free from obvious damage, liquid leakage, smoke or explosion, and it can work normally.

(14) Temperature cycling. The battery pack shall be tested in accordance with the provisions of 6.6.15, which shall not leak, smoke, ignite or explode; the appearance of the battery pack shall be free of cracks, no loss of quality, and the capacity shall not be lower than 70% of the initial state.

(15) Flame retardant properties. For battery packs with plastic casing and protective cover, the test shall be carried out in accordance with the provisions of 6.6.16. The outer casing shall comply with the provisions of Article 8.3.2 of the GB/T2408-2008, FH-1 (horizontal level) and 9.3.2 of FV-0 (vertical). Level) requirements.

(16) Insulation resistance. For a battery pack with a metal case, the insulation resistance of the battery pack's metal and cathode housings is not less than 2 MW.

24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
Our Company
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
Packing & Delivery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
24V 60Ah AGV Lithium Battery LiFePO4 Energy Storage Lithium Battery
FAQ

Q1. Can I have few free samples for evaluation?

A: Yes, free samples are ok, but not covering shipping cost

Q2. What about the lead time?

A: Samples needs 3-5 days

B: Mass production time is approx 2-3 weeks

Q3. Do you have any MOQ limit for bulk order?

A: MOQ=100pcs

Q4. How do you ship the goods and how long does it take to arrive?

A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days

B: Big quantity bulk order: Air shipping or Sea shipping

Q5. How to proceed an order for Lithium ion cell?

A: Pls confirm the cell models that you are interested in

B: We send cell specifications and best quotation to you for reference

C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly

D: After deposit or full payment confirmed, production started

Q6. Is it OK to print my logo on lithium ion cell product?

A: Yes. OEM is welcomed

Q7: Do you offer guarantee for the products?

A: Yes, 3-5 Years Warranty
