1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
Specifications
Model Number :
ZTG-1
Certification :
CE
Place of Origin :
WUXI
MOQ :
1
Price :
500-1000USD
Payment Terms :
D/P,T/T,Western Union,L/C,D/A
Supply Ability :
500 units/month
Delivery Time :
10-20 work days
Packaging Details :
55.00cm * 59.00cm * 65.00cm
Model :
ZTG-1
Voltage :
110V/220V
Motor Power :
1.5kw
Warranty :
1 Year
Way of Setting :
VFD Adjustment or Electromagnetic Speed Adjustment
Usage :
Welding and Cutting Turning
Noise Feature :
Stable Operation
Exported to :
Canada,USA,Russia,Saudi Arabia,Iraq,Greece,France
Rotaion Speed :
0.1-1rpm
Description
1 Ton Pipe Welding Rotator VFD Speed Control
1 Ton Welding Rotator for Small Tank Pressure Vessel Welding
1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
Product Function
  • Variable frequency speed control ensures smooth operation and high welding concentricity
  • Compact and lightweight, the unit can be easily moved by a single person and placed without site restrictions
  • Compatible with a wide range of welding machines, suitable for welding pipes, tanks, and flanges, as well as for DIY applications
Standard Factory Accessories
  • Powered Roller Stand ×1
  • Idler Roller Stand ×1
  • Digital Control Box ×1
  • Equipment Connection Cables, National Standard Power Cord
  • Spacing Adjustment Assembly
  • Complete Set of Fasteners
  • Original Hex Key Adjustment Tools

1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design
Production Specifications
Model
Loading Capacity

(kg)
Pipe/Tank Diameter

(mm)
Rubber Roller Dia. & Width (mm)
Roller Speed

(m/h)
Motor Power

(kw)
Speed Adjust
Rubber Roller
Steel Roller
ZTG-1
1000
20-800
Φ250*50
6-60
0.12
Variable Frequency Drive

(VFD)
ZTG-3
3000
50-1000
Φ250*50
0.12
ZTG-5
5000
Φ250-2300
Φ250*100
Φ240*20*2
0.75
ZTG-10
10000
Φ320-2800
Φ300*120
Φ290*25*2
1.1
ZTG-20
20000
Φ500-3500
Φ350*120
Φ340*30*2
1.5
ZTG-30
30000
Φ600-3800
Φ350*120
Φ340*30*2
2.2
ZTG-40
40000
Φ600-4200
Φ400*120
Φ390*40*2
3
ZTG-50
50000
Φ700-4500
Φ400*120
Φ390*40*2
4
ZTG-60
60000
Φ750-4800
Φ450*120
Φ440*50*2
4
ZTG-80
80000
Φ850-5000
Φ500*120
Φ490*60*2
5.5
ZTG-100
100000
Φ1000-5500
Φ500*120
Φ490*70*2
7.5
ZTG-150
150000
Φ1100-6000
Φ500*120
Φ600*Φ280
2*5.5
ZTG-250
250000
Φ1200-7000
/
Φ700*380
2*5.5
ZTG-500
500000
Φ1800-8000
/
Φ850*350
2*7.5
Key Features
  • Load Capacity: Rated 1 ton load bearing, stable support for small cylindrical workpieces, strong and durable
  • Stepless Speed Regulation: Infinitely variable speed control, adjustable rotating speed, smooth operation without jitter
  • PU Roller Design: High wear-resistant polyurethane roller, no damage to workpiece surface, anti-slip and high temperature resistant
  • Adjustable Structure: Flexible roller spacing adjustment, suitable for workpieces of different diameters
  • Simple Operation: Digital display control box, forward/reverse/stop switchable, easy to operate and high working efficiency
Application Scenarios
  • Pipe Welding: Suitable for automatic circumferential welding of small round pipes and tubular workpieces
  • Cylinder Fabrication: Ideal for welding, assembly and forming of small tank and cylinder parts
  • Flange Welding: Auxiliary rotating operation for flange and butt joint welding
  • Surface Polishing: Used for surface polishing, grinding and derusting of cylindrical workpieces
  • Spray Painting: Uniform rotating support for workpiece surface spraying and anti-corrosion coating

1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design

Production Process
  • Raw Material Cutting: Adopt standard steel materials, precise cutting according to drawing size to ensure uniform specification
  • Integral Welding Forming: Integrated welding of frame structure, firm welding seam, stable and not easy to deform
  • Precision Machining: Finish turning and milling of key parts, ensure assembly accuracy and running fit
  • Surface Treatment: Derusting, polishing and spray painting treatment, anti-corrosion and long service life
  • Assembly & Testing: Standardized assembly, strict no-load and load debugging before factory to guarantee stable performance

1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design1 Ton Load Capacity Pipe Welding Rotator with VFD Speed Control and PU Roller Design

Frequently Asked Questions
Q1. What is the maximum load of this roller rack?
A: This welding roller rack is rated for 1 ton load, suitable for light cylindrical workpieces within 1000kg.
Q2. What diameter of workpiece is applicable?
A: It fits workpiece diameter from 20mm to 800mm, with adjustable roller spacing for different sizes.
Q3. Is the speed adjustable?
A: Yes, it adopts stepless speed regulation, with smooth rotation and no jitter during operation.
Q4. Will the PU rollers scratch the workpiece?
A: The high-quality polyurethane roller is anti-slip and soft, causing no damage or scratches to the workpiece surface.
Q5. Is customized service available?
A: Support customized wire length, mobile base and anti-channeling device according to customer demands.
