Specifications
Supply Ability :
500 units/month
Speed Mode :
AC Variable Frequency Stepless Speed Regulation
Brand Name :
LEMAR
Model :
ZTG-3T
Model Number :
ZTG-3T
Max Loading Weight :
3Tons
MOQ :
1
Delivery Time :
10-20 work days
Wheel Roller Width :
25mm
Colour :
Customized
Payment Terms :
,T/T,D/P,D/A,L/C
Motor Power :
2*0.37kw
Price :
500-1000USD
Roller Linear Speed :
6-60m/H
Certification :
CE
Suitable Pipe Diameter :
50-2000mm
Place of Origin :
WUXI
Rubber Roller Diameter :
300mm
Packaging Details :
170.00cm *80.00cm * 55.00cm
Description
3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel
3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel
This 3T welding rotator is classic light-duty turning equipment for cylindrical workpieces rotary welding. It is widely used for circular seam welding, polishing, painting and flaw detection of small-diameter pipes, stainless steel tanks, heat exchangers and boiler barrels. Variable frequency speed control ensures smooth rotation during welding, greatly improving welding uniformity and reducing labor intensity.
3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel
Core Advantages
  • Stable Load Capacity: Rated load 3 tons, thickened base frame, solid roller support, no shaking during low-speed rotation.
  • VFD Stepless Speed Control: Rotating linear speed 0.1-1.2m/min adjustable, meet tack welding and finish welding demands.
  • Optional Roller Material: Cast steel roller for heavy high-temperature welding; PU roller to protect workpiece surface from scratches.
  • Compact Structure: Small floor space, easy to move and install, suitable for small workshop production lines.
  • Complete Safety Design: Emergency stop button, anti-offset baffle, overload protection for safe operation.
  • Customization Available: Adjustable roller spacing, remote control, mobile base, special voltage customization supported.

3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel

Technical Parameters
Item Specification
Rated Load 3 Ton
Applicable Workpiece Diameter 600mm-4000mm
Rotation Speed 0.1-1.2m/min stepless adjustment
Drive Type Single drive / Double drive optional
Roller Material Cast Steel / PU Roller
Control System Wired control box + E-stop
Power Supply 380V/415V 50/60Hz (customizable)
Certification CE, ISO9001
On-site Usage Benefits
  • Cut manual overturning cost: No need for overhead crane frequent turning for cylinder workpieces, reduce crane usage frequency and labor operation cost.
  • Improve welding molding quality: Constant rotation ensures even weld bead forming, reduce repair rate of circumferential welds.
  • Diversified working scenes: One machine realizes welding, polishing, sand blasting and flaw detection turnover, improve equipment utilization rate.
  • Low threshold operation: Workers can master operation within 10 minutes, no professional technical training required.

3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel

Optional Upgraded Configuration
  • Wireless remote controller: Realize remote start, stop and speed regulation, convenient for high-altitude welding operation
  • Rail travelling base: Realize horizontal movement of the whole rotator for long cylinder segmented processing
  • Height-adjustable support leg: Adapt to uneven workshop ground installation
  • High temperature resistant roller: For long-time high heat submerged arc welding working condition
Packaging & Shipment
  • Main frame fixed by steel wire + wooden box packaging for roller and electrical control parts, avoid collision damage during sea transportation
  • Complete operation manual, wiring diagram and wearing parts accessories delivered together
  • We cooperate with professional freight forwarders to arrange container loading, provide clear packing list for customs clearance

3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel3Ton Standard Welding Turning Roll Light Duty Welding Rotator for Pipe & Small Vessel

Provide your workpiece drawing and processing requirement, we will offer targeted technical plan and quotation within 24 hours
