GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
Specifications
Connectivity :
customized
Supply Ability :
400000pcs per month
VSWR :
<1.5
LNA Gain :
28dBi
Impedance :
50Ω
Model Number :
RM01010B
Material :
PC
Delivery Time :
10-15days
Place of Origin :
Guangdong, China
Frequency :
GPS GLONASS BEIDOU 4G 5G WIFI
Connector :
Fakra or Customized
Service :
OEM/ODM
MOQ :
50
Brand Name :
RIDA Antennaer
Polarity :
vertical
Packaging Details :
opp bag single pcs
Type :
GPS/GNSS Antenna
Certification :
ISO9001/IATF16949
Description
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Smart Center Control Telematics Connected Car Combo Antennas Customization scope:Antenna Performance,Appearance style, Cable length, Connector type

Products Description
Antenna Overview
GPS 4G WIFI all-in-one combination antenna for Telematics intelligent vehicle terminal equipment. The antenna combination function can be customized according to the actual demand, assisting the equipment to provide data acquisition, remote control, security services and other functions.
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
GPS 4G LTE MIMO 5G WIFI New Energy Vehicle Car Combo Antennas
Product Parameters
GPS / LTE / WIFI 3 IN 1 ANTENNA

Center Frequency
1575.42MHz±3 MHz
V.S.W.R
<1.5
Band Width
±5 MHz
Attenuation
fo±100MHz>30dB
Impendence
50 Ω
Peak Gain
>3dBic, Based on 7×7cm ground plane
Gain Coverage
>-4dBic at –90°<0<+90°(over 75% Volume)
Polarization
Right-handed Circular(RHCP)
GPS LNA specifications

LNA Gain(Without cable)
28dBi
Noise Figure
1.5dB
V.S.W.R
<1.65
DC Voltage
2.7V-5.0V±0.5V
DC current
15mA Max(5V DC)
LTE specifications

Frequency Range
698-2700MHz
V.S.W.R
<1.5
Band Width
±90/280 MHz
Gain
3.0 - 5.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
WIFI specifications

Frequency Range
2300-2500MHZ
V.S.W.R
1.5:1
Band Width
±100 MHz
Gain
3.0 - 5.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
