Specifications
Brand Name :
Trina
Model Number :
TSM-NEG9RC.27
Place of Origin :
China(Jiangsu)
Cell size :
210mm*210mm
Type :
PERC, Half Cell, IBC, HJT, hbc, Flexible, BIPV, Double-glass, MWT, N-TYPE, All Black, Bifacial, TOPCON
Panel Dimensions :
1762*1134*30 mm (69.06*43.15*1.18 inches)
Panel Efficiency :
21.8%
size :
1762*1134*30 mm
Solar Cells :
Monocrystalline
Frame :
30mm (1.18 inches) Anodized Aluminium Alloy, Black
Backsheet :
black
Cell Orientation :
144cells
Weight :
21.1kg (46.5lb)
Connector :
MC4 EVO2 / TS4*
Certificate :
IEC/ISO/UL
MOQ :
15300 watts
Price :
$0.10-0.13 / watt
Description
Product Description

Tier 1 Trina Bifacial Dual Glass NEG9RC.27 580W 700W 425W 430Watt 435W 440W 450W Solar Photovoltaic PV Panels
Tier 1 Trina Bifacial Dual Glass NEG9RC.27 580W 700W 425W 430Watt 435W 440W 450W Solar Photovoltaic PV Panels
Product Parameter

MECHANICAL DATA
Solar Cells Monocrystalline
NO. of cells 144 Cells
Module Dimensions 1762×1134×30 mm
Weight 21kG
Glass 1.6 mm (0.06 inches),
High Transmission, AR Coated Heat Strengthened Glass
Encapsulant material POE/EVA
Frame 30 mm Anodized Aluminium Alloy, black color
J-Box IP 68 rated, 3 diodes
Cables Photovoltaic Technology Cable 4.0 mm²
Portrait: 1400 mm
Length can be customized
ELECTRICAL DATA (STC)
Module Type TSM-425-450NEG9R.28
Maximum Power (Pmax/W) 425 430 435 440 445 450
Maximum Power Voltage-VMPP(V) 42.9 43.2 43.6 44.0 44.3 44.6
Maximum Power Current-IMPP(A) 9.92 9.96 9.99 10.01 10.05 10.09
Open Circuit Voltage-VOC(V) 50.9 51.4 51.8 52.2 52.6 52.9
Short Circuit Current-ISC(A) 10.56 10.59 10.64 10.67 10.71 10.74
Module Efficiency η m (%) 21.3 21.5 21.8 22.0 22.3 22.5
Power Output Tolerance 0~+5W
Maximum System Voltage 1500 V DC (IEC)
Maximum Series Fuse Rating 20A
Temperature Coefficient of PMAX - 0.30%/°C
Temperature Coefficient of VOC - 0.24%/°C
Temperature Coefficient of ISC +0.04%/°C
Operational Temperature -40°C -+85°C
