Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Huawei Olt Gpon 8 Ports ​EA5801-GP08-AC ETSI
Specifications
Brand Name :
Huawei
Model Number :
EA5801-CG08-AC
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$1022
Payment Terms :
T/T,Western Union
Supply Ability :
20pcs
Delivery Time :
2 - 4 working days
Packaging Details :
Huawei box
Condition :
Original New
Dimension :
43.6 mm × 442 mm × 222.3 mm
Description
Huawei SmartAX EA5801-CG04-AC OLT with 8 PON Ports GPON
Overview
The Huawei EA5801-CG04-AC ETSI is a compact OLT with 4 x G-PON and GPON combo ports and AC power supply. This SmartAX EA5801 model is a box-shaped Optical Line Terminal (OLT) that provides GPON or XG-PON&GPON combo access, supporting both Passive Optical LAN (POL) and Fiber to the Home (FTTH) solutions. It simplifies network architecture by carrying all services over a single fiber network, significantly reducing operational expenses.
Quick Specifications
Model Huawei SmartAX EA5801-CG04-AC ETSI
Dimensions (H * W * D) Without mounting ears: 43.6 mm * 442 mm * 222.3 mm
With IEC-standard mounting ears: 43.6 mm * 482.6 mm * 222.3 mm
With ETSI-standard mounting ears: 43.6 mm * 535 mm * 222.3 mm
Power Supply Mode AC power supply (dual for backup)
Working Voltage Range AC power supply: 100V to 240V
Rated Voltage AC power supply: 110V/220V
Maximum Input Current AC power supply: 2.5A
MAC Addresses 32,768
ARP Table 16,384
GE Upstream Ports 2 optical/electrical combo ports
10 GE/GE Upstream Ports 2
Number of Service Ports 4 x G-PON and GPON combo
Key Features
  • Compact Design: Lightweight 1U OLT suitable for small-scale access point convergence and enterprise deployment
  • PON Combo Technology: Supports smooth evolution from GPON to XG-PON with built-in WDM1r optical module
  • Versatile Installation: Can be deployed in both indoor and outdoor cabinets, including high-temperature environments
  • Cost-Efficient: Reduces manpower requirements and conserves cabinet space
Model Comparison
Model EA5801-GP08-AC EA5801-GP08-DC EA5801-CG04-AC EA5801-CG04-DC
Power Supply Mode AC power supply (dual for backup) DC power supply (dual for backup) AC power supply (dual for backup) DC power supply (dual for backup)
Working Voltage Range 100V to 240V -38.4V to -72V 100V to 240V -38.4V to -72V
Rated Voltage 110V/220V -48V/-60V 110V/220V -48V/-60V
Maximum Input Current 2.5A 6A 2.5A 6A
MAC Addresses 32,768 32,768 32,768 32,768
ARP Table 16,384 16,384 16,384 16,384
GE Upstream Ports 2 optical/electrical combo ports 2 optical/electrical combo ports 2 optical/electrical combo ports 2 optical/electrical combo ports
10 GE/GE Upstream Ports 2 2 2 2
Number of Service Ports 8 x GPON 8 x GPON 4 x G-PON and GPON combo 4 x G-PON and GPON combo
